GPA2-800

Reference CGPA2800

Check availability

2x720 WRMS | stereo | high-efficiency | amplifier

See more Features Resources

GPA2-800 is a stereo amplifier delivering 2 x 720 WRMS @ 4 Ω, and ready to drive 2Ω loudspeaker loads (4 x 8 Ω loudspeakers in parallel, per channel). GPA is a series of stereo amplifiers that become a perfect and affordable option in many audio projects. A very high efficiency and an auto standby function provide these amplifiers with a true green profile.

Installation options: 19" rack format (2RU)
Operating temperature: Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity: 85% HR
<85% HR
Storage temperature: Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity: 90% HR
<90% HR
Optional accessories: WPm series wall panels
Dimensions: Handle excluded: 482.6 x 88(2RU) x 280 mm / 19 x 3.46 x 11.02 in. (WxHxD)
Weight: 13.5 kg / 29.76 lb
Shipping dimensions: 550 x 120 x 500 mm / 21.66 x 4.73 x 19.9 in. (WxHxD)
Shipping weight: 15.3 kg / 33.73 lb
Status: New
Origin Production: Spain
EAN code: 8435071304948
Tariff code: 8518400000
Shipping Location: Spain
Width (cm): 55.00
Height (cm): 12.00
Depth (cm): 50.00
Vol. (dm3): 33.00
Gross Weight (kg): 15.30
Net Weight (kg): 13.50
Format: Unit
Warranty (months): 36
Frequency response: 20Hz - 55kHz (-1dB, -3dB)
Input sensitivity: 0dB
CMRR: 55dB

>55dB
Crosstalk: 55dB @ 1kHz

>55dB @ 1kHz
GPIs: x2 GPIs (0-10VDC) for volume control
AC mains requirement: 115V/230V @ 47-63Hz. Voltage changed internally (NOT BY SWITCH)
AC mains connector: AC socket connector (IEC)
SNR: 85dB 20Hz - 20kHz @ 1W/4Ω
>85dB 20Hz - 20kHz @ 1W/4Ω
Output connection type: Euroblock & speakon
Number of output channels: 2
Number of input channels: 2
Input connection type: Euroblock & XLR
Input impedance: 20kΩ
<20kΩ
THD + Noise: 0.05% @ 1kHz Full Power
<0.05% @ 1kHz Full Power
Damping factor: 200 1kHz @ 8Ω

>200 1kHz @ 8Ω
Cooling: Convection (fanless)
Power Consumption (IDLE): 47 W
Power Consumption (STBY): 16 W
Output configuration: 2 x 720 W RMS @ 4Ω
Input configuration: Analogue audio inputs
Power Consumption (1/3 POWER, @ 4Ω): pink noise, 613 W
Power Consumption (1/8 POWER, @ 4Ω): pink noise, 252 W /383 VA
Energy save: Auto standby function
Efficiency: 87% @ max power
AC protection: No
DC protection: No
VHF protection: No
Short-circuit protection: Yes
Clip limiter: Yes
Long term limiter: No
Thermal protection: Yes
Attenuators: Front panel knobs per channel
Output settings: Operating mode selector: STEREO, MONO - BRIDGE (Lo-Z)
Auto stand-by function: Rear panel switch
Auto stand-by time: 90 seconds
Signal Present: SP LED (Green) per channel
Cliping: CLIP LED (Red) per channel
Standby: STBY LED (Orange)
Filters: 50Hz 3rd order Butterworth High-Pass filter
Auto standby time: 90 seconds
Power ON/OFF: Front panel switch & indicator
Energy saving: Auto standby function
Power Consumption (STBY/SLEEP): 16 W
Auto standby function: Rear panel switch
Power Consumption (1/3 POWER, @ 4Ω all channels driven): pink noise, 613 W
Power Consumption (1/8 POWER, @ 4Ω all channels driven): pink noise, 252 W /383 VA

User Manual PDF EN CGPA2800

Download (1.13MB)

User Manual PDF ES CGPA2800

Download (1.13MB)

User Manual PDF DE CGPA2800

Download (1.14MB)

User Manual PDF FR CGPA2800

Download (1.14MB)

Data sheet CGPA2800

Download (374.09KB)

CE CGPA2800

Download (61.57KB)

FCC CGPA2800

Download (101.72KB)

Mechanical Diagram CGPA2800

Download (545.65KB)

Mechanical Diagram II CGPA2800

Download (3.52MB)
