PLAYER ZERO
CPLAYERZERO
Stock disponible
microSD | DLNA & Airplay | Streaming
PLAYER ZERO es un reproductor de audio estéreo de tamaño compacto y con posibilidad de reproducir contenidos musicales desde dispositivos de almacenamiento local (USB/MicroSD), "streamings" de Internet (radios online, etc.) y de intercambio de medios digitales (DLNA, Airplay).
- Tipo de conexión
- RCA stereo, minijack 3,5mm
- Opciones de instalación
- Desktop, rack (1/3 of 1UR)
- Temperatura de funcionamiento
- Min 0°C, +32°F
Max +35°C, +95°F - Humedad de funcionamiento
- 85% HR
< 85% HR - Temperatura de almacenamiento
- Min -10°C, +14°F
Max +50°C, +122°F - Humedad de almacenamiento
- 90% HR
< 90% HR - Accesorios incluidos
- AD/DC Power Supply, WiFi antenna, adhesive rubber feet, rack tray screws , GPI connector, warranty card and standard user guide
- Accesorios opcionales
- VEO-RACK19 Compatible
- Dimensiones
- 126.5 x 44 x 132 mm / 4.98 x 1.73 x 5.19 in. (WxHxD)
- Peso
- 0.6 kg / 1.32 lb
- Dimensiones de envío
- 220 x 60 x 450 mm / 8.66 x 2.36 x 17.71 in. (WxHxD)
- Peso del envío
- 0.8 Kg / 1.76 lb
- Estado
- New
- Origen Producción
- China
- Código EAN
- 8435071308960
- Código arancelario
- 8519890000
- Lugar de envío
- Spain
- Anchura (cm)
- 22
- Altura (cm)
- 6
- Profundidad (cm)
- 45
- Vol. (dm3)
- 5.94
- Peso bruto (kg)
- 0.86
- Peso neto (kg)
- 0.54
- Formato
- Unit
- Garantía (meses)
- 36
- Processor
- MIPS Single Core 64bits 580MHz
- Sampling rate
- 48 kHz
- Resolution
- 16 bit
- Frequency response
- 5Hz - 24kHz (-3dB)
- Output impedance
- 460Ω
- Crosstalk
- TBC
- Programing and control
- Web Application, RePLayer & Gallery.
Third party integration: JSON - GPIs
- 2 ports, Dry contact to ground, 3 pin Terminal block
- AC mains requirement
- 90-264VCA @ 50-60Hz
- AC mains connector
- International AC plugs set
- Consumo de energía
- 4.5 VA / 2.2 W
- Alimentación
- External, universal, 5VDC (included)
- Fecha de publicación
- 21/01/2022
- Indicadores LED
- Front panel: NET, SP, SD, Power
Rear panel: Wifi - Ethernet
- 1 RJ45 connector
10/100Mbps - Visor
- No
- THD + Ruido
- 0.008% (1kHz, 1Vrms)
< 0.008% (1kHz, 1Vrms) - USB
- Support USB 2.0 High Speed (480 Mbps)
- Ventilation
- Passive
- Dynamic range
- From -80 dB to 0 dB
TBC - Max output level
- 6dBV / 5kΩ
- Bit rate
- 32~320kbps
- Audio sources
- Local storage (USB & microSD), Internet radio, AirPlay, DLNA
- Compatible file formats
- mp3, ogg, WAV, FLAC, AIFF
- Number of outputs
- 2 x Stereo output (unbalanced)
- Retention time
- 240 hours aprox.
- Accuracy
- ±1 minute / month
- Buttons
- Rear panel: Factoty Defaults / Failse Safe (pin-hole)
- Micro SD
- Supports micro SD SDXC
- Capacity
- Up to 2TB
- File system
- Supports FAT16, FAT 32, VFAT and NTFS (read-only)
Multi-partition up to 1 - Playable audio files
- mp3, ogg, WAV, FLAC, AIFF, m3u, pls
- Files analysis
- 65354 playable folders
65354 playable folders within each folder
65354 playable files within each folder - Folder hierarchy
- Up to 8 containing the root directory
- Sorting
- UNICODE
Up to 100 folders, 100 files by folder
(Folders/files over 100 sorted in the FAT order) - Compatible playlist formats
- m3u, pls
- Wi-Fi
- 2.4GHz Wi-Fi, 802.11 b/g/n
Servicios e instalaciones implementadas
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SISTEMA
| Processor |
MIPS Single Core 64bits 580MHz |
|---|
FÍSICO
| Tipo de conexión |
RCA stereo, minijack 3,5mm |
|---|---|
| Opciones de instalación |
Desktop, rack (1/3 of 1UR) |
| Temperatura de funcionamiento |
Min 0°C, +32°F
Max +35°C, +95°F |
| Humedad de funcionamiento |
< 85% HR 85% HR |
| Temperatura de almacenamiento |
Min -10°C, +14°F
Max +50°C, +122°F |
| Humedad de almacenamiento |
< 90% HR 90% HR |
| Accesorios incluidos |
AD/DC Power Supply, WiFi antenna, adhesive rubber feet, rack tray screws , GPI connector, warranty card and standard user guide |
| Accesorios opcionales |
VEO-RACK19 Compatible |
| Dimensiones |
126.5 x 44 x 132 mm / 4.98 x 1.73 x 5.19 in. (WxHxD) |
| Peso |
0.6 kg / 1.32 lb |
| Dimensiones de envío |
220 x 60 x 450 mm / 8.66 x 2.36 x 17.71 in. (WxHxD) |
| Peso del envío |
0.8 Kg / 1.76 lb |
| Formato |
Unit |
LOGÍSTICA
| Estado |
New |
|---|---|
| Origen Producción |
China |
| Código EAN |
8435071308960
|
| Código arancelario |
8519890000 |
| Lugar de envío |
Spain |
| Anchura (cm) |
22 |
| Altura (cm) |
6 |
| Profundidad (cm) |
45 |
| Vol. (dm3) |
5.94 |
| Peso bruto (kg) |
0.86 |
| Peso neto (kg) |
0.54 |
| Garantía (meses) |
36 |
| Fecha de publicación |
21/01/2022 |
MICS
| Output impedance |
460Ω |
|---|
ELECTRICAL
| AC mains requirement |
90-264VCA @ 50-60Hz |
|---|---|
| AC mains connector |
International AC plugs set |
| Consumo de energía |
4.5 VA / 2.2 W |
| Alimentación |
External, universal, 5VDC (included) |
| Ventilation |
Passive |
AUDIO CONVERTERS
| Sampling rate |
48 kHz |
|---|---|
| Dynamic range |
TBC From -80 dB to 0 dB |
| Bit rate |
32~320kbps |
ANALOGUE AUDIO OUTPUT PORTS
| Crosstalk |
TBC |
|---|
CONNECTIVITY
| Programing and control |
Web Application, RePLayer & Gallery.
Third party integration: JSON |
|---|---|
| Ethernet |
1 RJ45 connector
10/100Mbps |
| Wi-Fi |
2.4GHz Wi-Fi, 802.11 b/g/n |
REMOTE CONTROL CONNECTIONS
| GPIs |
2 ports, Dry contact to ground, 3 pin Terminal block |
|---|
REAL-TIME CLOCK
| Retention time |
240 hours aprox. |
|---|---|
| Accuracy |
±1 minute / month |
LOCAL STORAGE
| Micro SD |
Supports micro SD SDXC |
|---|---|
| Capacity |
Up to 2TB |
| File system |
Supports FAT16, FAT 32, VFAT and NTFS (read-only)
Multi-partition up to 1 |
| Playable audio files |
mp3, ogg, WAV, FLAC, AIFF, m3u, pls |
| Files analysis |
65354 playable folders
65354 playable folders within each folder
65354 playable files within each folder |
| Folder hierarchy |
Up to 8 containing the root directory |
| Sorting |
UNICODE
Up to 100 folders, 100 files by folder
(Folders/files over 100 sorted in the FAT order) |
ANALOGUE AUDIO INPUTS
| THD + Ruido |
< 0.008% (1kHz, 1Vrms) 0.008% (1kHz, 1Vrms) |
|---|
ANALOGUE AUDIO OUTPUTS
| Number of outputs |
2 x Stereo output (unbalanced) |
|---|
CONTROL CONNECTIVITY
| USB |
Support USB 2.0 High Speed (480 Mbps) |
|---|
MONITORING AND CONTROL
| Indicadores LED |
Front panel: NET, SP, SD, Power
Rear panel: Wifi |
|---|---|
| Buttons |
Rear panel: Factoty Defaults / Failse Safe (pin-hole) |
MEDIA PLAYER
| Audio sources |
Local storage (USB & microSD), Internet radio, AirPlay, DLNA |
|---|---|
| Compatible file formats |
mp3, ogg, WAV, FLAC, AIFF |
| Compatible playlist formats |
m3u, pls |
LINE OUTPUTS
| Frequency response |
5Hz - 24kHz (-3dB) |
|---|---|
| Max output level |
6dBV / 5kΩ |
SCREEN/DISPLAY
| Resolution |
16 bit |
|---|---|
| Visor |
No |
