CORE
CCORE
Available
3x3 | Transmitter unit | WiSpeak | class 1 Bluetooth® | aux out
WiSpeak CORE is the transmitter device that communicates with all the receiver devices to create a WiSpeak wireless network, and takes the role of the Master Unit. Its main functions are to pair and send audio contents to all the receivers (TUBE, CUBE), keeping a stable communication with them, and send also individual configuration commands to each receiver if desired. It also takes care of the global configuration of the system: audio inputs in use, equalization, output levels, etc.
CORE is the Master Unit of the Ecler WiSpeak system. Together with TUBE, CUBE and GLOBE, provides a simple and fast wireless installation with up to 500m2 coverage. It includes a WiSpeak grip app available for Android and iOS, which can be used for an advanced set up and fine tuning of the Wireless Pro Audio system.
- Connection type
- 3-pin Euroblock, balanced
IN1: 2 x RCA, unbalanced
IN2: 2 x Euroblock 2-pin, balanced - Installation options
- Wall or under a surface (table, shelf,
cupboard, etc.) - Environmental
- TBC
- Enclosure material
- TBC
- Operating temperature
- Min: -10°C ; 14°F
Max: 40°C ; 104°F - Operating humidity
- 85% HR
<85% HR - Storage temperature
- Min: -10°C ; 14°F
Max: 40°C ; 104°F - Storage humidity
- 90% HR
<90% HR - Optional accessories
- WPaVOL for volume control
- Finished colour
- White (RAL 9003) - TBC
- Dimensions
- 225 x 120 x 40 mm / 8.9 x 4.7 x 1.6 in. (WxHxD)
- Weight
- 0.8 kg / 1.76 lb
- Pieces per box
- 1 unit
- Shipping dimensions
- 510 x 60 x 210 mm / 20.07 x 2.36 x 8.27 in. (WxHxD)
- Shipping weight
- 1.2 kg / 2.65 lb
- Status
- New
- EAN code
- 8435071312370
- Tariff code
- 8517699000
- Shipping Location
- Spain
- Input sensitivity
- -10dBV to 0dBV
- CMRR
- IN2: 60dB @ 1kHz
IN2: >60dB @ 1kHz - Number of output ports
- 1 x AUX OUT: Analog, Mono
- Output impedance
- 10kΩ
- Programing and control
- WiSpeak grip app
- AC mains requirement
- 100-240 VAC @ 50-60Hz, using supplied DC adapter
- AC mains connector
- 24VDC IN mains inlet
- Power consumption
- 0.5A at 24V
- Power supply
- External, universal Power Supply
- Mounting system
- TBC
- LED Indicators
- WiS, RX , WiS PAIR, SOURCE SELECTLEDs
- Input impedance
- 20kΩ
>20kΩ - Latency
- From TX Analog Audio IN to TX AUX OUT 700usec
From TX Analog Audio IN to RX AUX OUT 6ms
From TX Analog Audio IN to RX Speaker 6ms
From TX Analog Audio IN to TX AUX OUT <700usec
From TX Analog Audio IN to RX AUX OUT <6ms
From TX Analog Audio IN to RX Speaker <6ms - External MUTE
- Euroblock, 2-pin, Normally Open
- Tone control
- via WiSpeak grip app.
- Frequency band
- 5.18~5.32GHz, 5.55~5.825GHz (supported worldwide)
Up to 24 non-overlapping RF channels4
DFS support
U-NII 5.1 – 5.8GHz (supported worldwide)
Up to 24 non-overlapping RF channels4
DFS support - Coverage range
- Up to 12m from a TX to any paired RX, direct
line of sight - Audio channels
- WiSpeak CH 1&2
- Audio transmission
- 24bit uncompressed, 48kHz SR
- Digital Audio Sample size
- TBC
- Digital Audio Sampling rate
- 48kHz
- Digital Audio Frequency Response
- 10Hz – 20kHz (-1dB)
- Digital Audio converters
- ADC/DAC Resolution: 24 bits
Dynamic range
ADC: 96 dB
DAC: 98 dB - Pairing time
- Up to 120s
- Reconnection time
- Up to 120s
- Number of inputs
- 2
- THD + Noise
- IN 1&2: 0.015%
IN 1&2: <0.015% - Class
- Compliant 5.0, Class 1
- Range
- 25m (ideal conditions)
- Profiles
- A2DP1.3/AVRCP1.6/HFP1.6/HSP1.2
- Supported codecs
- SBC, AAC
- USB
- USB-C: Service & firmware updates
- Analogue remote control
- RJ-45: Compatible with WPa series analogue volume control panels
- Paring control
- via WiSpeak grip app./
front panel button - Source selection
- via WiSpeak grip app./
front panel button - Volume control
- via WiSpeak grip app./
front panel button / remote volume control - MUTE control
- via WiSpeak grip app./
GPI (External MUTE port) - Communication interfaces
- APP
- Processing
- TBC
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
PHYSICAL
| Connection type |
IN1: 2 x RCA, unbalanced
IN2: 2 x Euroblock 2-pin, balanced 3-pin Euroblock, balanced |
|---|---|
| Installation options |
Wall or under a surface (table, shelf,
cupboard, etc.) |
| Environmental |
TBC |
| Enclosure material |
TBC |
| Operating temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F |
| Operating humidity |
<85% HR 85% HR |
| Storage temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F |
| Storage humidity |
<90% HR 90% HR |
| Optional accessories |
WPaVOL for volume control |
| Finished colour |
White (RAL 9003) - TBC |
| Dimensions |
225 x 120 x 40 mm / 8.9 x 4.7 x 1.6 in. (WxHxD) |
| Weight |
0.8 kg / 1.76 lb |
| Pieces per box |
1 unit |
| Shipping dimensions |
510 x 60 x 210 mm / 20.07 x 2.36 x 8.27 in. (WxHxD) |
| Shipping weight |
1.2 kg / 2.65 lb |
| Mounting system |
TBC |
LOGISTICS
| Status |
New |
|---|---|
| EAN code |
8435071312370 |
| Tariff code |
8517699000 |
| Shipping Location |
Spain |
MICS
| Output impedance |
10kΩ |
|---|
ELECTRICAL
| AC mains requirement |
100-240 VAC @ 50-60Hz, using supplied DC adapter |
|---|---|
| AC mains connector |
24VDC IN mains inlet |
| Power consumption |
0.5A at 24V |
| Power supply |
External, universal Power Supply |
AUDIO CONVERTERS
| Latency |
From TX Analog Audio IN to TX AUX OUT <700usec
From TX Analog Audio IN to RX AUX OUT <6ms
From TX Analog Audio IN to RX Speaker <6ms From TX Analog Audio IN to TX AUX OUT 700usec From TX Analog Audio IN to RX AUX OUT 6ms From TX Analog Audio IN to RX Speaker 6ms |
|---|
ANALOGUE AUDIO OUTPUT PORTS
| Number of output ports |
1 x AUX OUT: Analog, Mono |
|---|
CONNECTIVITY
| Programing and control |
WiSpeak grip app |
|---|
WiS (RF WIRELESS DIGITAL AUDIO)
| Frequency band |
U-NII 5.1 – 5.8GHz (supported worldwide)
Up to 24 non-overlapping RF channels4
DFS support 5.18~5.32GHz, 5.55~5.825GHz (supported worldwide) Up to 24 non-overlapping RF channels4 DFS support |
|---|---|
| Coverage range |
Up to 12m from a TX to any paired RX, direct
line of sight |
| Audio channels |
WiSpeak CH 1&2 |
| Audio transmission |
24bit uncompressed, 48kHz SR |
| Digital Audio Sample size |
TBC |
| Digital Audio Sampling rate |
48kHz |
| Digital Audio Frequency Response |
10Hz – 20kHz (-1dB)
|
| Digital Audio converters |
ADC/DAC Resolution: 24 bits
Dynamic range
ADC: 96 dB
DAC: 98 dB |
| Pairing time |
Up to 120s |
| Reconnection time |
Up to 120s |
ANALOGUE AUDIO INPUTS
| Input sensitivity |
-10dBV to 0dBV |
|---|---|
| Number of inputs |
2 |
| THD + Noise |
IN 1&2: <0.015% IN 1&2: 0.015% |
BLUETOOTH AUDIO INPUT
| Class |
Compliant 5.0, Class 1 |
|---|---|
| Range |
25m (ideal conditions) |
| Profiles |
A2DP1.3/AVRCP1.6/HFP1.6/HSP1.2 |
| Supported codecs |
SBC, AAC |
CONTROL CONNECTIVITY
| External MUTE |
Euroblock, 2-pin, Normally Open |
|---|---|
| USB |
USB-C: Service & firmware updates |
| Analogue remote control |
RJ-45: Compatible with WPa series analogue volume control panels |
MONITORING AND CONTROL
| LED Indicators |
WiS, RX , WiS PAIR, SOURCE SELECTLEDs |
|---|---|
| Tone control |
via WiSpeak grip app. |
| Paring control |
via WiSpeak grip app./
front panel button |
| Source selection |
via WiSpeak grip app./
front panel button |
| Volume control |
via WiSpeak grip app./
front panel button / remote volume control |
| MUTE control |
via WiSpeak grip app./
GPI (External MUTE port) |
| Communication interfaces |
APP |
| Processing |
TBC |
LINE INPUTS
| CMRR |
IN2: >60dB @ 1kHz IN2: 60dB @ 1kHz |
|---|---|
| Input impedance |
>20kΩ 20kΩ |
