GXR-D15AAE
CLYGXRD15AAE
Check availability
Two 15" bi-amplified loudspeaker enclosure and AES3
Compact subwoofer enclosure, self-powered in class D and equipped with two 15″ (4″ coil) loudspeakers. Bi-amplified system offering high power levels from a compact enclosure.
- Effective Freq. Range
- Frequency range: 30 Hz - 140 Hz (-10dB)
Frequency response: 35 Hz - 125 Hz (± 3dB) - Coverage angle / Dispersion
- Omnidirectiona
- Power handling
- 2 x 15”, 4” voice coil
- Maximum SPL
- 134 dB / 140 dB peak
- Connection type
- USB (DSP updating) / Ethernet (OCS)
- Enclosure material
- 18 mm Premium birch plywood
- Dimensions
- 505 x 790 x 690 mm (HxWxD)
- Weight
- 63 Kg (139 lbs)
- Status
- New
- EAN code
- 8436612040479
- Tariff code
- 8518220000
- Shipping Location
- Spain
- Power supply
- 90 – 264V. 50/60 Hz with PFC
- Power handling per way
- 3000 W Class D with switching power supply & PFC
LF amplifier: 1 x 3000 W - Finish
- Polyurea coating, high grade resistant paint
- Audio inputs
- Analog / AES3 (optional)
- Display
- User control interface with 2.8” IPS screen
- AC connections
- 16A Neutrik powercon true1 TOP with looping output
- Processing (DSP)
- 96 KHz / 64 bit double-precision, DSP with FIR filter linear phase
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Effective Freq. Range |
Frequency range: 30 Hz - 140 Hz (-10dB)
Frequency response: 35 Hz - 125 Hz (± 3dB) |
|---|---|
| Coverage angle / Dispersion |
Omnidirectiona |
| Power handling |
2 x 15”, 4” voice coil |
| Maximum SPL |
134 dB / 140 dB peak |
| Power handling per way |
3000 W Class D with switching power supply & PFC
LF amplifier: 1 x 3000 W |
PHYSICAL
| Connection type |
USB (DSP updating) / Ethernet (OCS) |
|---|---|
| Enclosure material |
18 mm Premium birch plywood |
| Dimensions |
505 x 790 x 690 mm (HxWxD) |
| Weight |
63 Kg (139 lbs) |
| Finish |
Polyurea coating, high grade resistant paint |
POWERED
| Audio inputs |
Analog / AES3 (optional) |
|---|---|
| AC connections |
16A Neutrik powercon true1 TOP with looping output |
| Processing (DSP) |
96 KHz / 64 bit double-precision, DSP with FIR filter linear phase |
LOGISTICS
| Status |
New |
|---|---|
| EAN code |
8436612040479 |
| Tariff code |
8518220000 |
| Shipping Location |
Spain |
ELECTRICAL
| Power supply |
90 – 264V. 50/60 Hz with PFC |
|---|
SCREEN/DISPLAY
| Display |
User control interface with 2.8” IPS screen |
|---|
