VEO-MXH48T
CVEOMXH48T
Only a few left
4K HDBaseT | HDMI® 8x8 Matrix
VEO-MXH48T is a 8x8 HDBaseT and HDMI® matrix with support for up to 4K/UHD video resolution, 60 Hz and 4:4:4 chroma sampling. It includes 8 analogue audio inputs and 16 analogue and digital audio de-embedding outputs as well as EDID management, a LCD display and an integrated WebGUI that allows to configure and control the unit in a very user friendly way. The HDBaseT outputs can deliver 4K/UHD video up to 40m and Full HD video up to 70m as well as PoC power supply to HDBaseT compliant receivers. It includes a video downscaler and an independent audio matrix. The HDMI® sources can be routed using the front panel’s selection buttons, through the internal WEB GUI, serial commands, TCP/IP commands and IR signals. It is also HDCP 2.2 and 1.4 compliant and allows for bidirectional IR and RS-232 command controls. VEO-MXH48T can load and launch up to 8 presets which makes it a very suitable solution for professional applications that require video and audio HDMI® signals routing between 4K/UHD sources and displays with smart control management.
- Installation options
- 2U chassis hanging ear or desktop display
- Operating temperature
- Min. -5°C; 23°F
Max. 40°C; 104°F - Operating humidity
- 85% HR
- Included accessories
- UK, US, AU , EU cable
- Finished colour
- Black
- Dimensions
- 482.6 x 88 x 394 mm / 19 x 3.46 x 15.51 in. (WxHxD)
- Weight
- 8.3 Kg / 18.30 lb
- Shipping dimensions
- 530 x 190 x 570 mm / 20.87 x 7.48 x 22.44in. (WxHxD)
- Shipping weight
- 10.9 Kg / 24.03 lb
- Frequency response
- 20Hz-20KHz (±3dB)
- AC mains connector
- UK, US, AU , EU power cable plug
- Power consumption
- Built-in 2 AC to DC power module 24Vx2.4A, the maximum output power of 216W
- Video Input Connectors
- HDMI® Type A Female,18 Gbps
- Video Output Connectors
- HDMI® Type A Female, 18 Gbps
- Video Input Resolutions
- Input support 3840x2160/60 YUV444 HDMI
- Video Output Resolutions
- Output support 3840x2160/60 YUV444 HDMI
- Chroma Subsampling
- 4:4:4,4:2:2
- Colour Depth
- 8~12bit
- Colour Space
- RGB, YUV
- HDCP
- Support HDCP1.4/2.
- HDR
- Supports HDR10
- Audio Formats
- PCM2.0, Dolby autos, DTS-X
- Sample Rate
- 192 KHz
- Bit Depth
- 16 Bit
- ARC/eARC
- No
- Control Buttons
- 1xPower ON ,8xinput selection，8xoutput selection，1xpreset,
1xright，1xleft，1xup, 1xdown，1xlock - EDID Management
- Software, Pass-through, Auto
- Status Indicators
- 1xpower LED red，1x IR LED yellow,22xbutton LED blue
- Pass-through Connectors
- Euroblock, Jack 3,5mm
- Power supply
- PoC; Input 90-264 VAC @ 47-63Hz, Output 1 x 100-240 V AC @ 50-60Hz
- DC mains connector
- Built-in AC to DC power module
- Chassis material
- Metal
- Pass-through Protocols
- RS-232, IR
- Control Connectors
- RJ-45、Euroblock
- Audio De-Embedding
- Yes
- Audio Embedding
- Yes
- Control Protocols
- Web, Telnet, RS-232, IR
- Video Composing Capabilities
- 8 HDMI® inputs, 8 HDBaseT outputs, 8 HDMI® mirror outputs
- Screen Mirroring
- No
- Seamless Switching
- No
- Auto Source Selection
- No
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
PHYSICAL
| Installation options |
2U chassis hanging ear or desktop display |
|---|---|
| Operating temperature |
Min. -5°C; 23°F
Max. 40°C; 104°F |
| Operating humidity |
85% HR |
| Included accessories |
UK, US, AU , EU cable |
| Finished colour |
Black |
| Dimensions |
482.6 x 88 x 394 mm / 19 x 3.46 x 15.51 in. (WxHxD) |
| Weight |
8.3 Kg / 18.30 lb |
| Shipping dimensions |
530 x 190 x 570 mm / 20.87 x 7.48 x 22.44in. (WxHxD) |
| Shipping weight |
10.9 Kg / 24.03 lb |
| Chassis material |
Metal |
ELECTRICAL
| AC mains connector |
UK, US, AU , EU power cable plug |
|---|---|
| Power consumption |
Built-in 2 AC to DC power module 24Vx2.4A, the maximum output power of 216W |
| Power supply |
PoC; Input 90-264 VAC @ 47-63Hz, Output 1 x 100-240 V AC @ 50-60Hz |
| DC mains connector |
Built-in AC to DC power module |
DEVICE CONTROL
| Control Buttons |
1xPower ON ,8xinput selection，8xoutput selection，1xpreset,
1xright，1xleft，1xup, 1xdown，1xlock |
|---|---|
| EDID Management |
Software, Pass-through, Auto |
| Status Indicators |
1xpower LED red，1x IR LED yellow,22xbutton LED blue |
| Control Connectors |
RJ-45、Euroblock |
| Control Protocols |
Web, Telnet, RS-232, IR |
LINE OUTPUTS
| Frequency response |
20Hz-20KHz (±3dB) |
|---|
VIDEO PERFOMANCES
| Video Input Connectors |
HDMI® Type A Female,18 Gbps |
|---|---|
| Video Output Connectors |
HDMI® Type A Female, 18 Gbps |
| Video Input Resolutions |
Input support 3840x2160/60 YUV444 HDMI |
| Video Output Resolutions |
Output support 3840x2160/60 YUV444 HDMI |
| Chroma Subsampling |
4:4:4,4:2:2 |
| Colour Depth |
8~12bit |
| Colour Space |
RGB, YUV |
| HDCP |
Support HDCP1.4/2. |
| HDR |
Supports HDR10 |
| Video Composing Capabilities |
8 HDMI® inputs, 8 HDBaseT outputs, 8 HDMI® mirror outputs |
| Screen Mirroring |
No |
| Seamless Switching |
No |
| Auto Source Selection |
No |
AUDIO PERFORMANCES
| Audio Formats |
PCM2.0, Dolby autos, DTS-X |
|---|---|
| Sample Rate |
192 KHz |
| Bit Depth |
16 Bit |
| ARC/eARC |
No |
| Audio De-Embedding |
Yes |
| Audio Embedding |
Yes |
PASS-THROUGH CONTROL
| Pass-through Connectors |
Euroblock, Jack 3,5mm |
|---|---|
| Pass-through Protocols |
RS-232, IR |
