DROP6 BK
CDROP6BK
Check availability
6" | 2-way | 75 WRMS | ABS reinforced
DROP6 is a 6.5" 75W @ 8Ω 2-way pendant loudspeaker with a sleek design, featuring a 70/100V line transformer with 60/30/15 and 7.5W power selections, available in high and low impedance levels.
- Effective Freq. Range
- 90 Hz-20 kHz (-10dB)
- Coverage angle / Dispersion
- 112° Conical
- Power handling
- 75 W RMS / 300 W Peak
- Sensitivity
- 88 dB (1W/1m)
- Maximum SPL
- 107 dB continuous / 113 dB peak
- Recommended amplifier power
- 150 W RMS
- Ways
- 2-ways full range
- Low frequency driver
- 6.5" woofer
- High frequency driver
- 1" silk dome tweeter
- Nominal impedance
- 8Ω
- Crossover filter
- 1,65 kHz
- Connection type
- Double INPUT/LINK connector, Euroblock type
- Installation options
- Pendant
- Environmental
- IP53 rated
- Enclosure material
- ABS reinforced with fibreglass
- Grille material
- Aluminium
- Grille fixing system
- Bayonet mount system
- Flying points
- 2 x Steel wire hanging points
- Operating temperature
- Min: -20°C ; -4°F
Max: 70°C ; 158°F
Min: 0°C ; 32°F
Max: 35°C ; 95°F - Operating humidity
- 85% HR
<85% HR - Storage temperature
- Min: -10°C ; 14°F
Max: 50°C ; 122°F
Min: -20°C ; -4°F
Max: 70°C ; 158°F
- Storage humidity
- 90% HR
<90% HR - Included accessories
- 2 x Steel Wire for hanging 5 mts, 2 x 3C Euroblock connector
- Finished colour
- White (RAL9003) or Black (RAL9005)
- Dimensions
- 270 x 355mm / 10.6" x 14" (ØxH)
- Weight
- 4.2 kg / 9.26 lb
- Pieces per box
- 1 unit
- Shipping dimensions
- 380 x 325 x 370 mm / 14.9 x 12.8 x 15.5 in. (WxHxD)
- Shipping weight
- 5.5 kg / 12.12 lb
- Status
- New
- Origin Production
- China
- EAN code
- BK: 8435071314831
WH: 8435071314848 - Tariff code
- 8518210000
- Shipping Location
- Spain
- Width (cm)
- 37.00
- Height (cm)
- 37.00
- Depth (cm)
- 31.00
- Vol. (dm3)
- 42.44
- Gross Weight (kg)
- 5.50
- Net Weight (kg)
- 4.30
- Format
- Unit
- Warranty (months)
- 36 month
- Mounting system
- Steel wire hanging
- Power options (Hi Z Multi-tap)
- 70V/100V: 60W / 30W / 15W / 7.5W / 75W@8Ω
- Power type selector
- Back panel tap rotary selector
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Effective Freq. Range |
90 Hz-20 kHz (-10dB) |
|---|---|
| Coverage angle / Dispersion |
112° Conical |
| Power handling |
75 W RMS / 300 W Peak |
| Sensitivity |
88 dB (1W/1m) |
| Maximum SPL |
107 dB continuous / 113 dB peak |
| Recommended amplifier power |
150 W RMS |
| Power options (Hi Z Multi-tap) |
70V/100V: 60W / 30W / 15W / 7.5W / 75W@8Ω |
TRANSDUCERS
| Ways |
2-ways full range |
|---|---|
| Low frequency driver |
6.5" woofer |
| High frequency driver |
1" silk dome tweeter |
| Nominal impedance |
8Ω |
FILTERS
| Crossover filter |
1,65 kHz |
|---|
PHYSICAL
| Connection type |
Double INPUT/LINK connector, Euroblock type |
|---|---|
| Installation options |
Pendant |
| Environmental |
IP53 rated |
| Enclosure material |
ABS reinforced with fibreglass |
| Grille material |
Aluminium |
| Grille fixing system |
Bayonet mount system |
| Flying points |
2 x Steel wire hanging points |
| Operating temperature |
Min: 0°C ; 32°F
Max: 35°C ; 95°F Min: -20°C ; -4°F Max: 70°C ; 158°F |
| Operating humidity |
<85% HR 85% HR |
| Storage temperature |
Min: -10°C ; 14°F
Max: 50°C ; 122°F Min: -20°C ; -4°F Max: 70°C ; 158°F |
| Storage humidity |
<90% HR 90% HR |
| Included accessories |
2 x Steel Wire for hanging 5 mts, 2 x 3C Euroblock connector |
| Finished colour |
White (RAL9003) or Black (RAL9005) |
| Dimensions |
270 x 355mm / 10.6" x 14" (ØxH) |
| Weight |
4.2 kg / 9.26 lb |
| Pieces per box |
1 unit |
| Shipping dimensions |
380 x 325 x 370 mm / 14.9 x 12.8 x 15.5 in. (WxHxD) |
| Shipping weight |
5.5 kg / 12.12 lb |
| Format |
Unit |
| Mounting system |
Steel wire hanging |
| Power type selector |
Back panel tap rotary selector |
LOGISTICS
| Status |
New |
|---|---|
| Origin Production |
China |
| EAN code |
BK: 8435071314831
WH: 8435071314848 |
| Tariff code |
8518210000 |
| Shipping Location |
Spain |
| Width (cm) |
37.00
|
| Height (cm) |
37.00
|
| Depth (cm) |
31.00
|
| Vol. (dm3) |
42.44 |
| Gross Weight (kg) |
5.50
|
| Net Weight (kg) |
4.30
|
| Warranty (months) |
36 month
|
