VEO-XWT44E
CVEOXWT44E
Available
HDBaseT Wall Plate Transmitter
VEO-XWT44E is a HDBaseT transmitter in European 2-gang wallplate format. It allows to extend one 4K video signal up to 40m over a single Cat 5e/6 cable or a FullHD signal up to 70m when connected to VEO-XRT44. It supports real 4K video signals at 60Hz with 4:4:4 YUV chroma subsampling and HDR 10 with a maximum bandwidth of 18Gbps. With bidirectional PoC feature, the transmitter can be powered by the receiver and vice versa. A second front panel button can be used to switch ON/OFF a display via CEC or it can be alternatively programmed by IR learning or RS-232 to send two RS-232 commands, offering a simple and versatile control option.
- Installation options
- Wall
- Operating temperature
- Min: -10°C ; 14°F
Max: 55°C ; 131°F - Operating humidity
- 10 - 90% RH (no condensation)
- Included accessories
- Surface mount box EU, 2x Mounting screws, 3-pin Euroblock, 3x 2-pin Euroblock, Power Adapter (24V DC 1.25A), Quick guide and warranty
- Finished colour
- White
- Dimensions
- 146 × 86 × 42 mm / 5.75 x 3.39 x 1.65 in. (WxHxD)
- Weight
- 0.294 kg / 0.648 lb
- Shipping dimensions
- 183 x 105 x 133 mm / 7.2 x 4.13 x 5.24 in. (WxHxD)
- Shipping weight
- 0.8 Kg / 1.76 lb
- Status
- New
- Origin Production
- China
- EAN code
- 8435071312691
- Tariff code
- 8517620000
- Shipping Location
- Spain
- Frequency response
- 20Hz–20KHz, ±3dB
- Power consumption
- 22W Maximum
- Video Input Connectors
- 2x HDMI Type A Female, 2.0, 18 Gbps, 1x USB Type C
2x HDMI® Type A Female, 18 Gbps, 1x USB Type C - Video Input Resolutions
- Up to 4Kx2K@60Hz
- Chroma Subsampling
- 4:4:4
- Colour Depth
- 8 bit
- Colour Space
- YUV
- HDCP
- 2.2 compliant
- HDR
- HDR10
- HDMI Distance
- up to 10 meters / 33 ft with Ecler VEO cables
- Audio Formats
- Dolby Atmos, Dolby TrueHD, Dolby
Digital Plus, Dolby Digital, DTS-X, DTS-HD Master Audio, DTS 5.1, PCM. - Sample Rate
- 32 KHz, 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176.4 KHz, 192 KHz
- Bit Depth
- Up to 24-bit
- ARC/eARC
- No
- Control Buttons
- Reset button, Display On/Off button, Source/Auto button
- EDID Management
- Pass-through and smart management
- Status Indicators
- Link LED, HDCP LED, Power LED, HDMI IN 1/2 LED, USB-C LED
Link LED, HDCP LED, Power LED, HDMI® IN 1/2 LED, USB-C LED - Pass-through Connectors
- 2-pin Euroblock, 3-pin Euroblock
- Power supply
- PoC bidirectional; External: AC 100V - 240V @ 50-60Hz, Output: DC 24V-1.25A
- DC mains connector
- 2-pin Euroblock to connect DC 24V adapter
- Chassis material
- Plastic
- Pass-through Protocols
- IR, RS-232, CEC
- Control Connectors
- 2-pin Euroblock, 3-pin Euroblock, Type-C USB Female for FW update
- Control Protocols
- IR, RS-232
- Transmission Distance
- CAT5e/6 @ 4K up to 35 m / up to 115 feet
CAT6a/7 @ 4K up to 40 m/ up to 130 feet
CAT5e/6 @ 1080p up to 60 m / up to 197 feet
CAT6a/7 @ 1080p up to 70 m / up to 230 feet - Scaling Features
- No
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
PHYSICAL
| Installation options |
Wall |
|---|---|
| Operating temperature |
Min: -10°C ; 14°F
Max: 55°C ; 131°F |
| Operating humidity |
10 - 90% RH (no condensation) |
| Included accessories |
Surface mount box EU, 2x Mounting screws, 3-pin Euroblock, 3x 2-pin Euroblock, Power Adapter (24V DC 1.25A), Quick guide and warranty
|
| Finished colour |
White |
| Dimensions |
146 × 86 × 42 mm / 5.75 x 3.39 x 1.65 in. (WxHxD) |
| Weight |
0.294 kg / 0.648 lb
|
| Shipping dimensions |
183 x 105 x 133 mm / 7.2 x 4.13 x 5.24 in. (WxHxD) |
| Shipping weight |
0.8 Kg / 1.76 lb |
| Chassis material |
Plastic |
LOGISTICS
| Status |
New |
|---|---|
| Origin Production |
China |
| EAN code |
8435071312691 |
| Tariff code |
8517620000 |
| Shipping Location |
Spain |
ELECTRICAL
| Power consumption |
22W Maximum |
|---|---|
| Power supply |
PoC bidirectional; External: AC 100V - 240V @ 50-60Hz, Output: DC 24V-1.25A |
| DC mains connector |
2-pin Euroblock to connect DC 24V adapter |
DEVICE CONTROL
| Control Buttons |
Reset button, Display On/Off button, Source/Auto button |
|---|---|
| EDID Management |
Pass-through and smart management |
| Status Indicators |
Link LED, HDCP LED, Power LED, HDMI IN 1/2 LED, USB-C LED Link LED, HDCP LED, Power LED, HDMI® IN 1/2 LED, USB-C LED |
| Control Connectors |
2-pin Euroblock, 3-pin Euroblock, Type-C USB Female for FW update |
| Control Protocols |
IR, RS-232 |
LINE OUTPUTS
| Frequency response |
20Hz–20KHz, ±3dB |
|---|
VIDEO PERFOMANCES
| Video Input Connectors |
2x HDMI Type A Female, 2.0, 18 Gbps, 1x USB Type C 2x HDMI® Type A Female, 18 Gbps, 1x USB Type C |
|---|---|
| Video Input Resolutions |
Up to 4Kx2K@60Hz |
| Chroma Subsampling |
4:4:4 |
| Colour Depth |
8 bit |
| Colour Space |
YUV |
| HDCP |
2.2 compliant |
| HDR |
HDR10 |
| HDMI Distance |
up to 10 meters / 33 ft with Ecler VEO cables |
| Scaling Features |
No |
AUDIO PERFORMANCES
| Audio Formats |
Dolby Atmos, Dolby TrueHD, Dolby
Digital Plus, Dolby Digital, DTS-X, DTS-HD Master Audio, DTS 5.1, PCM. |
|---|---|
| Sample Rate |
32 KHz, 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176.4 KHz, 192 KHz |
| Bit Depth |
Up to 24-bit |
| ARC/eARC |
No |
PASS-THROUGH CONTROL
| Pass-through Connectors |
2-pin Euroblock, 3-pin Euroblock |
|---|---|
| Pass-through Protocols |
IR, RS-232, CEC |
HDBaseT SPECIFICATION
| Transmission Distance |
CAT5e/6 @ 4K up to 35 m / up to 115 feet
CAT6a/7 @ 4K up to 40 m/ up to 130 feet
CAT5e/6 @ 1080p up to 60 m / up to 197 feet
CAT6a/7 @ 1080p up to 70 m / up to 230 feet |
|---|
