| Processor |
2 x 32/64bit |
|---|
| Connection type |
Terminal block (symmetrical) |
|---|---|
| Installation options |
19" rack format (1RU) |
| Operating temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F |
| Operating humidity |
<85% HR 85% HR |
| Storage temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F |
| Storage humidity |
<90% HR 90% HR |
| Optional accessories |
WPa series control panels, WPTOUCH, eMPAGE |
| Dimensions |
482.6 x 44 x 253 mm / 19 x 1.73 x 9.96 in. (WxHxD) |
| Weight |
3.5 kg / 7.72 lb |
| Shipping dimensions |
590 x 70 x 380 mm / 23.23 x 2.76 x 14.96 in. (WxHxD) |
| Shipping weight |
4.5 kg / 9.92 lb |
| Format |
Unit |
| Status |
New |
|---|---|
| Origin Production |
Spain |
| EAN code |
8435071304979 |
| Tariff code |
8518400000 |
| Shipping Location |
Spain |
| Width (cm) |
59.00 |
| Height (cm) |
7.00 |
| Depth (cm) |
38.00 |
| Vol. (dm3) |
15.69 |
| Gross Weight (kg) |
4.50 |
| Net Weight (kg) |
3.50 |
| Warranty (months) |
36 |
| AC mains requirement |
90-264VAC @ 47-63Hz |
|---|---|
| AC mains connector |
IEC mains socket connector |
| Power consumption |
45VA |
| Secondary power supply |
+12VDC, 1.2A. max. (short circuit protected) |
| Sampling rate |
48kHz |
|---|---|
| Latency |
<2.9ms
2.9ms |
| Dynamic range |
AD:110dB, DA: 115dB |
| Number of input ports |
8, Mic/Line |
|---|---|
| Input impedanc |
Balanced, >4kΩ Balanced, 4kΩ |
| Number of output ports |
8, Line |
|---|---|
| Crosstalk |
Better than 90dB (100dB typ.) |
| Serial port |
RS-232 |
|---|---|
| Programing and control |
EclerNet manager (software) from v3.03r4 version, TPNET protocol, UCP control panels |
| Ethernet |
Ethernet Base-Tx 10/100Mb Auto X-Over CAT5 up to 100m. |
| Digital remote controls |
Remote Bus: Over twisted pairs; up to 1km (see specific specs.) |
|---|---|
| GPIs |
8, from 0 to 10VDC or TTL level |
| Retention time |
100 hours approx. (ambient temperature dependant) |
|---|---|
| Accuracy |
±1 minute / month |
| Input sensitivity |
-50dBV to +10dBV in 0.5dB step |
|---|
| Phantom power |
+42VDC, 5mA max. software switched |
|---|
| CMRR |
65dB typ. |
|---|---|
| Input impedance |
Balanced, 4kΩ |
| Max input level |
+27dBV +30dBu |
| Frequency response |
5Hz to 24kHz (-3dB) |
|---|---|
| THD + Noise |
THD+Noise @ 1kHz, 0dBV input (line) <0.004%
THD+Noise @ 1kHz, -40dBV input (mic.) <0.008% THD+Noise @ 1kHz, 0dBV input (line) 0.004% THD+Noise @ 1kHz, -40dBV input (mic.) 0.008% |
| Max output level |
+18dBV +21dBu |
| Resolution |
24bit AKM |
|---|
