eCMP8
CECMP8
Available
8" | 2-way | 150 WRMS | Musical projector
eCMP8 is a 150W high efficiency musical projector ready for outdoor applications due to its waterproof and sun screening building material (IP56). It performs an 8" LF driver and 1.4" HF coaxial driver, 150W @ 8Ω nominal power and 70/100V line transformer with 37.5/75/150W/ 8Ω power options.
- Effective Freq. Range
- 87 Hz-20 kHz (-10dB)
- Coverage angle / Dispersion
- 135°x135° (HxV)
- Power handling
- 150 W RMS / 600 W Peak
- Sensitivity
- 97dB (1W/1m)
- Maximum SPL
- 119 dB continuous / 125 dB peak
- Recommended amplifier power
- 300 W RMS
- Ways
- 2-ways long throw
- Low frequency driver
- 8"
- High frequency driver
- 1,4" coaxial
- Nominal impedance
- 8Ω
- Crossover filter
- 2,1 kHz
- Connection type
- Terminal block (input+output)
- Environmental
- IP56
- Enclosure material
- Polypropylene
- Grille material
- Aluminium
- Operating temperature
- Min: -10°C ; 14°F
Max: 40°C ; 104°F
Min: -20°C ; -4°F
Max: 70°C ; 158°F
- Operating humidity
- 85% HR
<85% HR - Storage temperature
- Min: -10°C ; 14°F
Max: 40°C ; 104°F
Min: -20°C ; -4°F
Max: 70°C ; 158°F
- Storage humidity
- 90% HR
<90% HR - Finished colour
- Grey (RAL 538C)
- Dimensions
- 300 x 302 x 280 mm /11.8 x 11.9 x 11.02 in. (WxHxD)
(If the mounting bracket is added the total depth will be 334mm/13.2") - Weight
- 11.0 kg / 24.3 lb
- Pieces per box
- Unit
- Shipping dimensions
- 360 x 355 x 335 mm / 14.17 x 13.98 x 13.19 in. (WxHxD)
- Shipping weight
- 11.7 kg / 25.79 lb
- Status
- New
- Origin Production
- China
- EAN code
- 8435071307901
- Tariff code
- 8518220000
- Shipping Location
- Spain
- Width (cm)
- 36.00
- Height (cm)
- 35.50
- Depth (cm)
- 33.50
- Vol. (dm3)
- 42.81
- Gross Weight (kg)
- 11.70
- Net Weight (kg)
- 10.70
- Format
- Unit
- Warranty (months)
- 36
- Mounting system
- Hot-dipped galvanized steel U-bracket
- Power options (Hi Z Multi-tap)
- 100V: 150W / 75W / 37,5W / OFF and 8Ω
70V: 75W / 37,5W / 18,75W / OFF and 8Ω
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Effective Freq. Range |
87 Hz-20 kHz (-10dB) |
|---|---|
| Coverage angle / Dispersion |
135°x135° (HxV) |
| Power handling |
150 W RMS / 600 W Peak |
| Sensitivity |
97dB (1W/1m) |
| Maximum SPL |
119 dB continuous / 125 dB peak |
| Recommended amplifier power |
300 W RMS |
| Power options (Hi Z Multi-tap) |
100V: 150W / 75W / 37,5W / OFF and 8Ω
70V: 75W / 37,5W / 18,75W / OFF and 8Ω |
TRANSDUCERS
| Ways |
2-ways long throw |
|---|---|
| Low frequency driver |
8" |
| High frequency driver |
1,4" coaxial |
| Nominal impedance |
8Ω |
FILTERS
| Crossover filter |
2,1 kHz |
|---|
PHYSICAL
| Connection type |
Terminal block (input+output) |
|---|---|
| Environmental |
IP56 |
| Enclosure material |
Polypropylene |
| Grille material |
Aluminium |
| Operating temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F Min: -20°C ; -4°F Max: 70°C ; 158°F |
| Operating humidity |
<85% HR 85% HR |
| Storage temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F Min: -20°C ; -4°F Max: 70°C ; 158°F |
| Storage humidity |
<90% HR 90% HR |
| Finished colour |
Grey (RAL 538C) |
| Dimensions |
300 x 302 x 280 mm /11.8 x 11.9 x 11.02 in. (WxHxD)
(If the mounting bracket is added the total depth will be 334mm/13.2") |
| Weight |
11.0 kg / 24.3 lb |
| Pieces per box |
Unit |
| Shipping dimensions |
360 x 355 x 335 mm / 14.17 x 13.98 x 13.19 in. (WxHxD) |
| Shipping weight |
11.7 kg / 25.79 lb |
| Format |
Unit |
| Mounting system |
Hot-dipped galvanized steel U-bracket |
LOGISTICS
| Status |
New |
|---|---|
| Origin Production |
China |
| EAN code |
8435071307901 |
| Tariff code |
8518220000 |
| Shipping Location |
Spain |
| Width (cm) |
36.00 |
| Height (cm) |
35.50 |
| Depth (cm) |
33.50 |
| Vol. (dm3) |
42.81 |
| Gross Weight (kg) |
11.70 |
| Net Weight (kg) |
10.70 |
| Warranty (months) |
36 |
