eGPA2-300
eGPA2-300
eGPA2-300
eGPA2-300

eGPA2-300

CEGPA2300
Available
2x300 WRMS | class D | stereo | amplifier
See more Features Resources

eGPA2-300 is a 2x300 W RMS @ 4 ohm, high efficiency multichannel amplifier (class D). Auto stand-by function and fanless design, 100% silent. Thermal and overload protections. Anti-clip system.
Installation options
19" rack format (1RU)
Operating temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity
85% HR
<85% HR
Storage temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity
90% HR
<90% HR
Dimensions
440 x 44 x 221 mm / 17.32 x 1.73 x 8.70 in. (WxHxD)
Weight
3.4 kg / 7.5 lb
Shipping dimensions
380 x 70 x 590 mm / 14.97 x 2.76 x 23.23 in. (WxHxD)
Shipping weight
4.6 kg / 10.14 lb
Status
New
Origin Production
Spain
EAN code
8435071306447
Tariff code
8518400000
Shipping Location
Spain
Width (cm)
38.00
Height (cm)
7.00
Depth (cm)
59.00
Vol. (dm3)
15.69
Gross Weight (kg)
4.60
Net Weight (kg)
3.40
Format
Unit
Warranty (months)
36
Frequency response
20Hz - 25kHz (-1dB, -3dB)
Input sensitivity
0dB
CMRR
55dB
>55dB
Crosstalk
55dB @ 1kHz
>55dB @ 1kHz
AC mains requirement
See characteristics in the back of the unit
AC mains connector
AC socket connector (IEC)
Power supply
Universal, regulated switch mode with PFC (Power Factor Correction)
SNR
85dB 20Hz - 20kHz @ 1W/4Ω
>85dB 20Hz - 20kHz @ 1W/4Ω
Output connection type
Euroblock
Number of output channels
2
Number of input channels
2
Input connection type
Euroblock
Input impedance
20kΩ
>20kΩ
THD + Noise
0.05% @ 1kHz Full Power
<0.05% @ 1kHz Full Power
Damping factor
150 1kHz @ 8Ω
>150 1kHz @ 8Ω
Cooling
Convection (fanless)
Power Consumption (IDLE)
26 W
Power Consumption (STBY)
22 W
Output configuration
2x300 W RMS @ 4 Ω
Input configuration
Analogue audio inputs
Power Consumption (1/3 POWER, @ 4Ω)
pink noise, 251 W
Power Consumption (1/8 POWER, @ 4Ω)
pink noise, 110 W
Energy save
Auto standby function
Efficiency
87% @ max power
AC protection
No
DC protection
No
VHF protection
No
Short-circuit protection
Yes
Clip limiter
Yes
Long term limiter
No
Thermal protection
Yes
Attenuators
Front panel knobs per channel
Output settings
Operating mode selector: STEREO, MONO - BRIDGE (Lo-Z)
Auto stand-by function
Front pannel switch
Auto stand-by time
90 seconds
Signal Present
SP LED (Green) per channel
Cliping
CLIP LED (Red) per channel
Standby
STBY LED (Orange)
Filters
15Hz 3rd order Butterworth Hihg-Pass filter
Auto standby time
90 seconds
Amplification technology
Class D
Power ON/OFF
Front panel switch & indicator
Thermal
TH LED (Red)
Protect
PROT LED (Red)
Energy saving
Auto standby function
Power Consumption (STBY/SLEEP)
22 W
Auto standby function
Front pannel switch
Power Consumption (1/3 POWER, @ 4Ω all channels driven)
pink noise, 251 W
Power Consumption (1/8 POWER, @ 4Ω all channels driven)
pink noise, 110 W

Services and facilities implemented

see solutions

Ecler at Áltima

Multi-zone sound system installation designed to improve speech intelligibility and ensure consistent coverage across indoor and outdoor ceremony spaces.

Centers of worship

Void at Dido The Real Show

Immersive sound that complements gastronomy, live entertainment and music in every corner of the venue.

Leisure

Opus | Auracast™ at Eurovisión 2026

Auracast™ enabled assisted listening at Eurovision 2026 in an extremely complex RF environment, ensuring audio accessibility without the need for wired infrastructure.

Leisure

LYNX EN TERRAZA BAGHEERA

Terraza Bagheera in Toledo debuts its new sound system, delivering balanced coverage across all areas, from the dance floor to the most remote corners.

Leisure

New Ecler price list available

News

Void Acoustics Air 12 now available

News

Ecler en Zegna

Retail

Void at Dido The Real Show

Immersive sound that enhances gastronomy, live performance, and music in every corner.

Void Acoustics

Ecler en el campo del CD Tondela

Sports & Wellness

Void Acoustics en primera edición Soundit Festiv

Void Acoustics

¿Necesitas ayuda?

Contacta con el comercial más cercano

Encuentra a tu comercial

Si ya conoces a tu comercial asignado inicia sesión para contactar directamente

O déjanos aquí tus dudas y nuestros expertos te ayudarán

SYSTEM
Number of input channels 2
PHYSICAL
Installation options 19" rack format (1RU)
Operating temperature Min: -10°C ; 14°F Max: 40°C ; 104°F
Operating humidity <85% HR
85% HR
Storage temperature Min: -10°C ; 14°F Max: 40°C ; 104°F
Storage humidity <90% HR
90% HR
Dimensions 440 x 44 x 221 mm / 17.32 x 1.73 x 8.70 in. (WxHxD)
Weight 3.4 kg / 7.5 lb
Shipping dimensions 380 x 70 x 590 mm / 14.97 x 2.76 x 23.23 in. (WxHxD)
Shipping weight 4.6 kg / 10.14 lb
Format Unit
LOGISTICS
Status New
Origin Production Spain
EAN code 8435071306447
Tariff code 8518400000
Shipping Location Spain
Width (cm) 38.00
Height (cm) 7.00
Depth (cm) 59.00
Vol. (dm3) 15.69
Gross Weight (kg) 4.60
Net Weight (kg) 3.40
Warranty (months) 36
ELECTRICAL
AC mains requirement See characteristics in the back of the unit
AC mains connector AC socket connector (IEC)
Power supply Universal, regulated switch mode with PFC (Power Factor Correction)
ANALOGUE AUDIO OUTPUT PORTS
Crosstalk >55dB @ 1kHz
55dB @ 1kHz
CHANNELS
Number of output channels 2
Output configuration 2x300 W RMS @ 4 Ω
Input configuration Analogue audio inputs
SIGNAL
SNR >85dB 20Hz - 20kHz @ 1W/4Ω
85dB 20Hz - 20kHz @ 1W/4Ω
Damping factor >150 1kHz @ 8Ω
150 1kHz @ 8Ω
POWER CONSUMPTION
Power Consumption (IDLE) 26 W
Power Consumption (STBY) 22 W
Power Consumption (1/3 POWER, @ 4Ω) pink noise, 251 W
Power Consumption (1/8 POWER, @ 4Ω) pink noise, 110 W
Power Consumption (STBY/SLEEP) 22 W
Power Consumption (1/3 POWER, @ 4Ω all channels driven) pink noise, 251 W
Power Consumption (1/8 POWER, @ 4Ω all channels driven) pink noise, 110 W
TECHNOLOGIES
Cooling Convection (fanless)
Energy save Auto standby function
Efficiency 87% @ max power
Amplification technology Class D
Energy saving Auto standby function
PROTECTIONS
AC protection No
DC protection No
VHF protection No
Short-circuit protection Yes
Clip limiter Yes
Long term limiter No
Thermal protection Yes
SETTINGS
Output settings Operating mode selector: STEREO, MONO - BRIDGE (Lo-Z)
Auto stand-by function Front pannel switch
Auto stand-by time 90 seconds
Auto standby function Front pannel switch
MONITORING
Signal Present SP LED (Green) per channel
Cliping CLIP LED (Red) per channel
Standby STBY LED (Orange)
Thermal TH LED (Red)
Protect PROT LED (Red)
ANALOGUE AUDIO INPUTS
Input sensitivity 0dB
MONITORING AND CONTROL
Auto standby time 90 seconds
MIC INPUTS
Filters 15Hz 3rd order Butterworth Hihg-Pass filter
LINE INPUTS
CMRR >55dB
55dB
Input connection type Euroblock
Input impedance >20kΩ
20kΩ
LINE OUTPUTS
Frequency response 20Hz - 25kHz (-1dB, -3dB)
Output connection type Euroblock
THD + Noise <0.05% @ 1kHz Full Power
0.05% @ 1kHz Full Power
LOCAL CONTROL
Attenuators Front panel knobs per channel
Power ON/OFF Front panel switch & indicator
OUTPUT POWER - All channels driven @ 1%THD
