HSA2-400ES
CHSA2400ES
Check availability
2x400 WRMS | Energy Star | stereo | amplifier
HSA2-400ES is a stereo amplifier with low and high impedance powered outputs. A very high efficiency and its auto stand-by function provide this amplifier with a true green profile (Energy Star© Certified).
- Installation options
- 19" rack format (2RU)
- Operating temperature
- Min: -10°C ; 14°F
Max: 40°C ; 104°F - Operating humidity
- 85% HR
- Storage temperature
- Min: -10°C ; 14°F
Max: 40°C ; 104°F - Storage humidity
- 90% HR
- Optional accessories
- WPm series wall panels
- Dimensions
- 482.6 x 88 x 373 mm / 19 x 3.46 x 14.68 in. (WxHxD)
- Weight
- 16.4 kg / 36.15 lb
- Shipping dimensions
- 510 x 200 x 570 mm / 20.1 x 7.88 x 22.45 in. (WxHxD)
- Shipping weight
- 19.3 kg / 42.55 lb
- Frequency response
- 20Hz – 40kHz (-1dB, -3dB)
- Input sensitivity
- 0dB
- CMRR
- 55dB
- Crosstalk
- 55dB @ 1 kHz
- GPIs
- x2 GPIs (0-10VDC) for volume control
- AC mains requirement
- 115V/230V @ 47-63Hz. Voltage changed internally (NOT BY SWITCH)
- AC mains connector
- AC socket connector (IEC)
- SNR
- 85dB @ 1W/4Ω, 20Hz – 20kHz
- Output connection type
- Euroblock
- Number of output channels
- 2
- Number of input channels
- 2
- Input connection type
- XLR, Euroblock
- Max output power @ 100V
- 400W @ 25Ω
- Input impedance
- 20kΩ (10kΩ unbalanced)
- THD + Noise
- 0.05% @ 1 kHz Full Power
- Damping factor
- 360 1kHz @ 8Ω
- Cooling
- Convection (fanless)
- Power Consumption (IDLE)
- 25 W
- Output configuration
- 2 x 400 W RMS output (4Ω and 70/ 100V line level)
- Input configuration
- Balanced inputs
- Efficiency
- 85% @ max power
- AC protection
- No
- DC protection
- No
- VHF protection
- No
- Short-circuit protection
- Yes
- Clip limiter
- Yes
- Long term limiter
- No
- Thermal protection
- Yes
- Attenuators
- Front panel knobs per channel
- Output settings
- Lo-Z/Hi-Z outputs
- Signal Present
- SP LED (Green) per channel
- Cliping
- CLIP LED (Red) per channel
- Standby
- STBY LED (Orange) per channel
- Filters
- 50Hz 3rd order Butterworth High-Pass filter
- Auto standby time
- ≤120s
- Power ON/OFF
- Front panel switch & indicator
- Thermal
- TH LED (Red)
- Energy saving
- Auto standby function
- Power Consumption (STBY/SLEEP)
- 0.5 W
- Auto standby function
- Rear panel switch
- Power Consumption (1/3 POWER, @ 4Ω all channels driven)
- pink noise, 334W
- Power Consumption (1/8 POWER, @ 4Ω all channels driven)
- pink noise, 143 W / 204 VA
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Number of input channels |
2 |
|---|
PHYSICAL
| Installation options |
19" rack format (2RU) |
|---|---|
| Operating temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F |
| Operating humidity |
85% HR |
| Storage temperature |
Min: -10°C ; 14°F
Max: 40°C ; 104°F |
| Storage humidity |
90% HR |
| Optional accessories |
WPm series wall panels |
| Dimensions |
482.6 x 88 x 373 mm / 19 x 3.46 x 14.68 in. (WxHxD) |
| Weight |
16.4 kg / 36.15 lb |
| Shipping dimensions |
510 x 200 x 570 mm / 20.1 x 7.88 x 22.45 in. (WxHxD) |
| Shipping weight |
19.3 kg / 42.55 lb |
ELECTRICAL
| AC mains requirement |
115V/230V @ 47-63Hz. Voltage changed internally (NOT BY SWITCH) |
|---|---|
| AC mains connector |
AC socket connector (IEC) |
ANALOGUE AUDIO OUTPUT PORTS
| Crosstalk |
55dB @ 1 kHz |
|---|
REMOTE CONTROL CONNECTIONS
| GPIs |
x2 GPIs (0-10VDC) for volume control |
|---|
CHANNELS
| Number of output channels |
2 |
|---|---|
| Output configuration |
2 x 400 W RMS output (4Ω and 70/ 100V line level) |
| Input configuration |
Balanced inputs |
SIGNAL
| SNR |
85dB @ 1W/4Ω, 20Hz – 20kHz |
|---|---|
| Damping factor |
360 1kHz @ 8Ω |
POWER CONSUMPTION
| Power Consumption (IDLE) |
25 W |
|---|---|
| Power Consumption (STBY/SLEEP) |
0.5 W |
| Power Consumption (1/3 POWER, @ 4Ω all channels driven) |
pink noise, 334W |
| Power Consumption (1/8 POWER, @ 4Ω all channels driven) |
pink noise, 143 W / 204 VA |
TECHNOLOGIES
| Cooling |
Convection (fanless) |
|---|---|
| Efficiency |
85% @ max power |
| Energy saving |
Auto standby function |
PROTECTIONS
| AC protection |
No |
|---|---|
| DC protection |
No |
| VHF protection |
No |
| Short-circuit protection |
Yes |
| Clip limiter |
Yes |
| Long term limiter |
No |
| Thermal protection |
Yes |
SETTINGS
| Output settings |
Lo-Z/Hi-Z outputs |
|---|---|
| Auto standby function |
Rear panel switch |
MONITORING
| Signal Present |
SP LED (Green) per channel |
|---|---|
| Cliping |
CLIP LED (Red) per channel |
| Standby |
STBY LED (Orange) per channel |
| Thermal |
TH LED (Red) |
ANALOGUE AUDIO INPUTS
| Input sensitivity |
0dB |
|---|
MONITORING AND CONTROL
| Auto standby time |
≤120s |
|---|
MIC INPUTS
| Filters |
50Hz 3rd order Butterworth High-Pass filter |
|---|
LINE INPUTS
| CMRR |
55dB |
|---|---|
| Input connection type |
XLR, Euroblock |
| Input impedance |
20kΩ (10kΩ unbalanced) |
LINE OUTPUTS
| Frequency response |
20Hz – 40kHz (-1dB, -3dB) |
|---|---|
| Output connection type |
Euroblock |
| THD + Noise |
0.05% @ 1 kHz Full Power |
LOCAL CONTROL
| Attenuators |
Front panel knobs per channel |
|---|---|
| Power ON/OFF |
Front panel switch & indicator |
OUTPUT POWER - All channels driven @ 1%THD
| Max output power @ 100V |
400W @ 25Ω |
|---|
