AURA-8L150
CAURA8L150
Available
Multichannel amplifier | 8x150 W RMS @ 4Ω | Class D
AURA-8L150 is a multichannel, 8x150 W RMS @ 4 Ω, high efficiency amplifier (class D). AURA Series are built with the highest robustness for long lasting performances with special power supply circuitry designed for optimized electrical consumption and are 100% silent featuring convection cooling system. AURA Series also features the possibility of linking channels to the first input by selecting it on the rear panel, adjustable auto stand-by level, overload and thermal protection, PFC and anti-clipping system.
- Operating temperature
- -10º to 50º C
14º to 122º F
- Operating humidity
- 5-85% RH, non-condensing
- Storage temperature
- -10⁰ to 50⁰ C
14⁰ to 122⁰ F - Storage humidity
- 5-85% RH, non-condensing
- Included accessories
- Rear rack support
- Dimensions
- 482.6x44x414 mm / 19x1.73x16.29 in. (WxHxD)
- Weight
- 6.3 kg / 13.9 lb
- Shipping dimensions
- 590x75x585mm / 23.23x2.95x23.03 in. (WxHxD)
- Shipping weight
- 8.35 Kg / 18.41 lb
- Status
- New
- Origin Production
- China
- EAN code
- 8435071343947
- Width (cm)
- 59
- Height (cm)
- 7.5
- Depth (cm)
- 58.5
- Vol. (dm3)
- 25.89
- Gross Weight (kg)
- 8.35
- Net Weight (kg)
- 6.25
- Format
- Unit
- Warranty (months)
- 60
- Frequency response
- 15Hz-30kHz (-3dB, 1W @ 4Ω)
- Input sensitivity
- 0 dBV
2,21 dBu
1 Vrms - CMRR
- 55 Typ (from 20Hz-20kHz)
- Crosstalk
- 80dB (@ 1kHz)
- AC mains requirement
- 100-240 V @ 50-60Hz (±10%)
- AC mains connector
- IEC C14 inlet (10Amax, Power cord 10Amax)
- Power supply
- Universal, regulated SMPS with PFC
- SNR
- 100 dBA (from 20Hz - 20kHz)
- Output connection type
- 2-pin Euroblock. Pitch: 5 mm
- Power
- 24,0 W
54,5 VA
24,36 W
31,9 VA
34,6 W
66,9 VA
34,7 W
41,47 VA
217,7 W
246,3 VA
221,9 W
227,6 VA
391,8 W
424,9 VA
400,8 W
408,5 VA - Number of output channels
- 8
- Number of input channels
- 8
- Input connection type
- Analogue, 3-pin Euroblock, balanced, pitch 3,5 mm
- Input impedance
- 500kΩ (balanced)
- Max input level
- +12dBV
14,21 dBu - THD + Noise
- 0,01 % (from 1W to full power output @ 4Ω)
- Damping factor
- 150 (DF @ 8 Ω, 20 Hz - 400 Hz)
- Cooling
- Convection (fanless)
- Input configuration
- Input link to CH1 selector per input
- Efficiency
- 76% (1/4 POWER, @ 4Ω, 230VAC)
- DC protection
- Yes
- Short-circuit protection
- Yes
- Clip limiter
- Yes
- Thermal protection
- Yes
- Attenuators
- Front panel knobs per channel
VOL (default)/BYPASS option) (VOL/BYPASS selectable by a switch at the bottom)
- Signal Present
- SIGNAL LED (Green) per channel (trigger @- 40 dBV)
- Cliping
- CLIP LED (Red) per channel
- Standby
- AUTO STANDBY ON/OFF LED (Green) per unit
- Amplification technology
- Class D
- Power ON/OFF
- Front panel switch (green LED indicator)
- Thermal
- TH LED (Orange) by pairs of channels (combined PROT/TH LED)
- Protect
- PROT LED (Red) by pairs of channels (Combined PROT/TH LED)
- Voltage gain
- 27,8 dB
- Power factor correction
- 0,92 (Output Power 1/4 Max Output Power)
- HF protection
- Yes
- Standby / Mute
- AUTO STANDBY (Orange) by pairs of channels
- On
- ON LED (Green) per unit
- Energy saving
- Auto Standby function selectable (Auto Standby by pairs of channels)
- Current Draw
- 0,237 Arms
0,278 Arms
0,291 Arms
0,361 Arms
1,073 Arms
1,853 Arms
1,992 Arms
3,592 Arms - Thermal Loss
- 20,64 kcal/h
81,91 BTU/h
20,95 kcal/h
83,14 BTU/h
29,76 kcal/h
118,09 BTU/h
29,84 kcal/h
118,43 BTU/h
58,08 kcal/h
230,51 BTU/h
61,70 kcal/h
244,85 BTU/h
79,29 kcal/h
314,68 BTU/h
86,96 kcal/h
345,12 BTU/h - RUN/SLEEP mode
- Auto Standby function
Front panel button
(Auto Standby ON/OFF button per unit. -50dB (default) or -40dB, internally selectable. Auto stand-by time: 60 seconds)
- Link
- LINK LED (White) per chanel
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Number of input channels |
8 |
|---|
PHYSICAL
| Operating temperature |
-10º to 50º C
14º to 122º F
|
|---|---|
| Operating humidity |
5-85% RH, non-condensing |
| Storage temperature |
-10⁰ to 50⁰ C
14⁰ to 122⁰ F |
| Storage humidity |
5-85% RH, non-condensing |
| Included accessories |
Rear rack support |
| Dimensions |
482.6x44x414 mm / 19x1.73x16.29 in. (WxHxD) |
| Weight |
6.3 kg / 13.9 lb |
| Shipping dimensions |
590x75x585mm / 23.23x2.95x23.03 in. (WxHxD) |
| Shipping weight |
8.35 Kg / 18.41 lb |
| Format |
Unit |
POWERED
| Power |
391,8 W
424,9 VA 217,7 W 246,3 VA 34,6 W 66,9 VA 24,0 W 54,5 VA 24,36 W 31,9 VA 34,7 W 41,47 VA 400,8 W 408,5 VA 221,9 W 227,6 VA |
|---|
LOGISTICS
| Status |
New |
|---|---|
| Origin Production |
China |
| EAN code |
8435071343947 |
| Width (cm) |
59 |
| Height (cm) |
7.5 |
| Depth (cm) |
58.5 |
| Vol. (dm3) |
25.89 |
| Gross Weight (kg) |
8.35 |
| Net Weight (kg) |
6.25 |
| Warranty (months) |
60 |
ELECTRICAL
| AC mains requirement |
100-240 V @ 50-60Hz (±10%) |
|---|---|
| AC mains connector |
IEC C14 inlet (10Amax, Power cord 10Amax) |
| Power supply |
Universal, regulated SMPS with PFC |
| Power factor correction |
0,92 (Output Power 1/4 Max Output Power) |
ANALOGUE AUDIO OUTPUT PORTS
| Crosstalk |
80dB (@ 1kHz) |
|---|
CHANNELS
| Number of output channels |
8 |
|---|---|
| Input configuration |
Input link to CH1 selector per input |
SIGNAL
| SNR |
100 dBA (from 20Hz - 20kHz) |
|---|---|
| Damping factor |
150 (DF @ 8 Ω, 20 Hz - 400 Hz) |
| Voltage gain |
27,8 dB |
TECHNOLOGIES
| Cooling |
Convection (fanless) |
|---|---|
| Efficiency |
76% (1/4 POWER, @ 4Ω, 230VAC) |
| Amplification technology |
Class D |
| Energy saving |
Auto Standby function selectable (Auto Standby by pairs of channels) |
PROTECTIONS
| DC protection |
Yes |
|---|---|
| Short-circuit protection |
Yes |
| Clip limiter |
Yes |
| Thermal protection |
Yes |
| HF protection |
Yes |
MONITORING
| Signal Present |
SIGNAL LED (Green) per channel (trigger @- 40 dBV) |
|---|---|
| Cliping |
CLIP LED (Red) per channel |
| Standby |
AUTO STANDBY ON/OFF LED (Green) per unit |
| Thermal |
TH LED (Orange) by pairs of channels (combined PROT/TH LED) |
| Protect |
PROT LED (Red) by pairs of channels (Combined PROT/TH LED) |
| Standby / Mute |
AUTO STANDBY (Orange) by pairs of channels |
| On |
ON LED (Green) per unit |
| Link |
LINK LED (White) per chanel |
ANALOGUE AUDIO INPUTS
| Input sensitivity |
0 dBV
2,21 dBu
1 Vrms |
|---|
LINE INPUTS
| CMRR |
55 Typ (from 20Hz-20kHz) |
|---|---|
| Input connection type |
Analogue, 3-pin Euroblock, balanced, pitch 3,5 mm |
| Input impedance |
500kΩ (balanced) |
| Max input level |
+12dBV
14,21 dBu |
LINE OUTPUTS
| Frequency response |
15Hz-30kHz (-3dB, 1W @ 4Ω) |
|---|---|
| Output connection type |
2-pin Euroblock. Pitch: 5 mm |
| THD + Noise |
0,01 % (from 1W to full power output @ 4Ω) |
LOCAL CONTROL
| Attenuators |
Front panel knobs per channel
VOL (default)/BYPASS option) (VOL/BYPASS selectable by a switch at the bottom)
|
|---|---|
| Power ON/OFF |
Front panel switch (green LED indicator) |
| RUN/SLEEP mode |
Auto Standby function
Front panel button
(Auto Standby ON/OFF button per unit. -50dB (default) or -40dB, internally selectable. Auto stand-by time: 60 seconds)
|
OUTPUT POWER - All channels driven @ 1%THD
POWER & HEAT @120VAC - STANDBY/SLEEP MODE
| Current Draw |
1,853 Arms 1,073 Arms 0,291 Arms 0,237 Arms 0,278 Arms 0,361 Arms 3,592 Arms 1,992 Arms |
|---|---|
| Thermal Loss |
79,29 kcal/h
314,68 BTU/h 58,08 kcal/h 230,51 BTU/h 29,76 kcal/h 118,09 BTU/h 20,64 kcal/h 81,91 BTU/h 20,95 kcal/h 83,14 BTU/h 29,84 kcal/h 118,43 BTU/h 86,96 kcal/h 345,12 BTU/h 61,70 kcal/h 244,85 BTU/h |
