IC6i BK
CIC6iBK
Available
6.5" | 2-way | 40 WRMS | Frameless magnetic grill
IC6i 2-way loudspeaker is the perfect option for 70/100 V and low impedance sound solutions. It mounts a 6.5” woofer and a 1" tweeter in a discreet design.
IC series provides excellent sound quality thanks to their infinite baffle philosophy and a top-performance high frequency transducer.
- Effective Freq. Range
- 75Hz-20kHz (-10dB)
- Coverage angle / Dispersion
- 163° conical
- Power handling
- 40W RMS / 160W Peak
- Sensitivity
- 90dB (1W/1m)
93dB (1W/1m) - Maximum SPL
- 106dB continuous / 112dB peak
109dB continuous / 115dB peak - Recommended amplifier power
- 80 W RMS
- Ways
- 2-ways full range
- Low frequency driver
- 6.5" woofer
- High frequency driver
- 1" tweeter
- Nominal impedance
- 8Ω
- Connection type
- Clip-type input terminals
- Installation options
- In-ceiling / In-wall
- Enclosure material
- ABS plastic
- Grille material
- Iron
- Grille fixing system
- Magnets
- Operating temperature
- Min: -20°C ; -4°F
Max: 70°C ; 158°F
- Operating humidity
- 85% HR
- Storage temperature
- Min: -20°C ; -4°F
Max: 70°C ; 158°F
- Storage humidity
- 90% HR
- Included accessories
- Cutting template
- Optional accessories
- Ecler IC-TB6
- Finished colour
- White (RAL 9003) / Black (RAL 9005)
- Dimensions
- 213 x 213 x 72 mm. / 8.39 x 8.39 x 2.83 in. (WxHxD)
- Weight
- 1.6 Kg / 3.53 lb
- Pieces per box
- 2
- Shipping dimensions
- 265x260x255 mm. / 10.43x10.24x10.04 in. (WxHxD)
- Shipping weight
- 4 kg / 8.82 lb
- Mounting system
- 3 rotating tabs
- Power options (Hi Z Multi-tap)
- 100V: 2.5 / 5 / 7.5 / 15W
70V: 1.25 / 2.5 / 3.75 / 7.5W
- Recommended cut out diameter
- 180 mm / 7.09in.
180mm / 7.09in. - External diameter
- 213 mm / 8.39in.
213mm / 8.39in. - Required depth
- 73 mm / 2.87in.
73mm / 2.87in. - Internal diameter
- 178 mm / 7.01in.
205mm / 8.07in.
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Effective Freq. Range |
75Hz-20kHz (-10dB) |
|---|---|
| Coverage angle / Dispersion |
163° conical |
| Power handling |
40W RMS / 160W Peak |
| Sensitivity |
90dB (1W/1m) 93dB (1W/1m) |
| Maximum SPL |
106dB continuous / 112dB peak 109dB continuous / 115dB peak |
| Recommended amplifier power |
80 W RMS |
| Power options (Hi Z Multi-tap) |
100V: 2.5 / 5 / 7.5 / 15W
70V: 1.25 / 2.5 / 3.75 / 7.5W
|
TRANSDUCERS
| Ways |
2-ways full range |
|---|---|
| Low frequency driver |
6.5" woofer |
| High frequency driver |
1" tweeter |
| Nominal impedance |
8Ω |
PHYSICAL
| Connection type |
Clip-type input terminals |
|---|---|
| Installation options |
In-ceiling / In-wall |
| Enclosure material |
ABS plastic |
| Grille material |
Iron |
| Grille fixing system |
Magnets |
| Operating temperature |
Min: -20°C ; -4°F
Max: 70°C ; 158°F
|
| Operating humidity |
85% HR |
| Storage temperature |
Min: -20°C ; -4°F
Max: 70°C ; 158°F
|
| Storage humidity |
90% HR |
| Included accessories |
Cutting template |
| Optional accessories |
Ecler IC-TB6 |
| Finished colour |
White (RAL 9003) / Black (RAL 9005) |
| Dimensions |
213 x 213 x 72 mm. / 8.39 x 8.39 x 2.83 in. (WxHxD) |
| Weight |
1.6 Kg / 3.53 lb |
| Pieces per box |
2 |
| Shipping dimensions |
265x260x255 mm. / 10.43x10.24x10.04 in. (WxHxD) |
| Shipping weight |
4 kg / 8.82 lb |
| Mounting system |
3 rotating tabs |
| Recommended cut out diameter |
180mm / 7.09in. 180 mm / 7.09in. |
| External diameter |
213mm / 8.39in. 213 mm / 8.39in. |
| Required depth |
73mm / 2.87in. 73 mm / 2.87in. |
| Internal diameter |
205mm / 8.07in. 178 mm / 7.01in. |
