Cyclone 55.1 - Negro
Cyclone 55.1 - Negro
Cyclone 55.1 - Negro
Cyclone 55.1 - Negro
Cyclone 55.1 - Negro
Cyclone 55.1 - Negro

Cyclone 55.1 - Negro

CVOIT2804
Check availability
Double 5" weatherproof (IP55) acoustic enclosure for installation. Includes wall bracket.
See more Features Resources

The Cyclone 55 offers high levels of fidelity and definition from an ultra-compact and visually appealing format, in a weather-protected package with an IP-55 rating that is ideally suited to coastal outdoor environments, ranging from beach bars, resorts and cruise ships, to hotels and public spaces. With a dedicated bracket, the Cyclone 55 can be installed quickly and securely, and its wide range of adjustment allows the loudspeaker’s wide dispersion pattern to be accurately aimed at large audiences, using the least number of loudspeakers. The loudspeaker shall be a passive two-way system consisting of two high power 5” (125 mm) direct radiating reflex loaded low frequency (LF) transducers and 1” (25 mm) diameter co-axial soft dome tweeters high frequency (HF) transducers mounted in an open V-baffle enclosure.
Effective Freq. Range
70 Hz - 23 kHz ±3 dB
Coverage angle / Dispersion
110°H x 70°V
Power handling
120 W AES
Sensitivity
92 dB 1W/1m
Maximum SPL
110 dB cont, 114 dB peak
112 dB cont, 118 dB peak
Low frequency driver
2 x 5” LF, 2 x 1” soft dome HF tweeters
Nominal impedance
16 Ω
Crossover filter
3.6 kHz passive
Connection type
Phoenix connectors with link out
Environmental
IP-55 (BS EN 60529:1992 +A2:2013)
Enclosure material
Fibreglass
Weight
3.2 kg (7.1 lbs)
Status
New
EAN code
IT2804
IT2804
IT2805
IT2807
Tariff code
8518220000
Shipping Location
Spain
Mounting system
Wall bracket included
Type 51 plate
Finish
Smooth cellulose
Rigging
Wall bracket included, type 51 plate
Driver
2 x 5” LF, 2 x 1” soft dome HF tweeters
