Venu 15 V2 - Negro
CVOIT2751
Check availability
15" acoustic cabinet for installation.
As the largest Venu loudspeaker, the Venu 15 V2 is the latest addition to this range. Benefitting from all the recent enhancements within the rest of the rest of the Venu V2 series, this 15” based speaker has an impressive frequency response of 50 Hz – 20 kHz ±3 dB and efficiency of 99 dB 1w/1m. Providing the sound as the main speaker system in a small to medium-sized venue is effortless for a Venu 15 V2.
The loudspeaker shall be a passive two-way system consisting of one high power 15” (381 mm), direct radiating, reflex loaded, low frequency (LF) transducer and 1” (25 mm) diameter composite plastic exit, high frequency (HF) compression driver mounted on a user rotatable asymmetrical horn in a trapezoidal enclosure fitted with a wraparound grille and rotatable badge.
- Effective Freq. Range
- 50 Hz - 20 kHz ±3 dB
- Coverage angle / Dispersion
- 90°-40°H x 60°V rotatable
- Power handling
- 450 W AES
- Sensitivity
- 99 dB 1w/1m
- Maximum SPL
- 125 dB cont, 128 dB peak
125 dB cont, 131 dB peak - Low frequency driver
- 1 x 15” LF, 1 x 1” HF compression driver
- Nominal impedance
- 8 Ω
- Crossover filter
- 2.1 kHz passive
- Connection type
- 1 x Phoenix with link out and 1 x speakON™ with link out
- Enclosure material
- 15 mm birch plywood
- Grille material
- Perforated steel with foam filter
- Weight
- 31 kg (68.3 lbs)
- Status
- New
- EAN code
- IT2751
IT2751
IT2841 - Tariff code
- 8518220000
- Shipping Location
- Spain
- Mounting system
- Yoke bracket positions 4 x M8 fixing points for type 80 plate Optional top hat
- Finish
- Textured polyurethane
- Rigging
- Yoke bracket positions, 4 x M8 fixing points for type 80 plate, optional top hat
- Driver
- 1 x 15” LF, 1 x 1” HF compression driver
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
SYSTEM
| Effective Freq. Range |
50 Hz - 20 kHz ±3 dB |
|---|---|
| Coverage angle / Dispersion |
90°-40°H x 60°V rotatable |
| Power handling |
450 W AES |
| Sensitivity |
99 dB 1w/1m |
| Maximum SPL |
125 dB cont, 128 dB peak 125 dB cont, 131 dB peak |
TRANSDUCERS
| Low frequency driver |
1 x 15” LF, 1 x 1” HF compression driver |
|---|---|
| Nominal impedance |
8 Ω |
| Driver |
1 x 15” LF, 1 x 1” HF compression driver |
FILTERS
| Crossover filter |
2.1 kHz passive |
|---|
PHYSICAL
| Connection type |
1 x Phoenix with link out and 1 x speakON™ with link out |
|---|---|
| Enclosure material |
15 mm birch plywood |
| Grille material |
Perforated steel with foam filter |
| Weight |
31 kg (68.3 lbs) |
| Mounting system |
Yoke bracket positions 4 x M8 fixing points for type 80 plate Optional top hat |
| Finish |
Textured polyurethane |
| Rigging |
Yoke bracket positions, 4 x M8 fixing points for type 80 plate, optional top hat |
LOGISTICS
| Status |
New |
|---|---|
| EAN code |
IT2751
IT2841 IT2751 |
| Tariff code |
8518220000 |
| Shipping Location |
Spain |
