| Processor |
MIPS Single Core 64bits 580MHz |
|---|
| Connection type |
RCA stereo, minijack 3,5mm |
|---|---|
| Installation options |
Desktop, rack (1/2 of 1UR) |
| Operating temperature |
Min 0°C, +32°F
Max +35°C, +95°F |
| Operating humidity |
< 85% HR 85% HR |
| Storage temperature |
Min -10°C, +14°F
Max +50°C, +122°F |
| Storage humidity |
< 90% HR 90% HR |
| Included accessories |
AD/DC Power Supply, WiFi antenna, adhesive rubber feet, rack tray screws , GPI connector, warranty card and standard user guide |
| Optional accessories |
1UHRMKIT |
| Dimensions |
198.5 x 44 x 132 mm / 7.81 x 1.73 x 5.19 in. (WxHxD) |
| Weight |
0.8 kg / 1.76 lb |
| Shipping dimensions |
220 x 60 x 450 mm / 8.66 x 2.36 x 17.71 in. (WxHxD) |
| Shipping weight |
1 kg / 2.20 lb |
| Format |
Unit |
| Status |
New |
|---|---|
| Origin Production |
China |
| EAN code |
8435071309004
|
| Tariff code |
8519890000 |
| Shipping Location |
Spain |
| Width (cm) |
22 |
| Height (cm) |
6 |
| Depth (cm) |
45 |
| Vol. (dm3) |
5.94 |
| Gross Weight (kg) |
1.1 |
| Net Weight (kg) |
0.8 |
| Warranty (months) |
36 |
| Release Date |
21/01/2022 |
| Output impedance |
460Ω |
|---|
| AC mains requirement |
90-264VCA @ 50-60Hz |
|---|---|
| AC mains connector |
International AC plugs set |
| Power consumption |
6 VA / 3 W |
| Power supply |
External, universal, 5VDC (included) |
| Ventilation |
Passive |
| Sampling rate |
48 kHz |
|---|---|
| Dynamic range |
TBC From -80 dB to 0 dB |
| Bit rate |
32~320kbps |
| Crosstalk |
TBC |
|---|
| Programing and control |
Web Application, RePLAYER & Ecler Gallery.
Third party integration: JSON |
|---|---|
| Ethernet |
1 RJ45 connector 10/100Mbps |
| Wi-Fi |
2.4GHz Wi-Fi, 802.11 b/g/n |
| GPIs |
2 ports, Dry contact to ground, 3 pin Terminal block |
|---|
| Retention time |
240 hours aprox. |
|---|---|
| Accuracy |
±1 minute / month |
| Micro SD |
Supports micro SD SDXC |
|---|---|
| Capacity |
Up to 2TB |
| File system |
Supports FAT16, FAT 32, VFAT and NTFS (read-only)
Multi-partition up to 1 |
| Playable audio files |
mp3, ogg, WAV, FLAC, AIFF, m3u, pls |
| Files analysis |
65354 playable folders
65354 playable folders within each folder
65354 playable files within each folder |
| Folder hierarchy |
Up to 8 containing the root directory |
| Sorting |
UNICODE
Up to 100 folders, 100 files by folder
(Folders/files over 100 sorted in the FAT order) |
| THD + Noise |
< 0.008% (1kHz, 1Vrms) 0.008% (1kHz, 1Vrms) |
|---|
| Number of outputs |
2 x Stereo output (unbalanced) |
|---|
| USB |
Support USB 2.0 High Speed (480 Mbps) |
|---|
| LED Indicators |
Front panel: NET, SP, SD, Power
Rear panel: Wifi |
|---|---|
| Buttons |
Front panel: Encoder, Enter, Esc, Play/pause, Next, Prev, Stop
Rear panel: Factoty Defaults / Failse Safe (pin-hole) |
| Audio sources |
Local storage (USB & microSD), Internet radio, AirPlay, DLNA |
|---|---|
| Compatible file formats |
mp3, ogg, WAV, FLAC, AIFF |
| Compatible playlist formats |
m3u, pls |
| Frequency response |
5Hz - 24kHz (-3dB) |
|---|---|
| Max output level |
6dBV / 5kΩ |
| Resolution |
16 bit |
|---|---|
| Display |
LCD Alphanumeric 2x16 cells |
