VEO-DACS4
CVEODACS4
Available
DAC Converter And ARC Extractor
VEO-DACS4 allows converting digital audio signals from HDMI® ARC and S/PDIF optical or coaxial inputs to a stereo analogue signal. In addition it can be used to convert digital S/PDIF audio coming from the optical input to coaxial and vice versa. It provides a stereo unbalanced analogue output on Euroblock and RCA connectors. Function mode is selectable through the onboard switch.
- Installation options
- Desktop - VEO-RACK19
- Operating temperature
- 0 to 40°C (+32 to +104 °F)
- Operating humidity
- 5 - 90% RH (no condensation)
- Included accessories
- Power supply, Euroblock 5-pin connectors, warranty card
- Optional accessories
- VEO-RACK19
- Finished colour
- Black
- Dimensions
- 96.2 x 57.5 x 21 mm / 3.79 x 2.26 x 0.83 in. (WxHxD)
- Weight
- 0.14 kg / 0.309 lb
- Shipping dimensions
- 210 x 60 x 150 mm / 8.27 x 2.36 x 5.91 lb
- Shipping weight
- 0.4 kg / 0.88 lb
- Status
- New
- Origin Production
- China
- EAN code
- 8435071315913
- Tariff code
- 8517620000
- Shipping Location
- Spain
- Width (cm)
- 21
- Height (cm)
- 6
- Depth (cm)
- 15
- Vol. (dm3)
- 1.89
- Gross Weight (kg)
- 0.4
- Net Weight (kg)
- 0.16
- Format
- Unit
- Warranty (months)
- 36
- Frequency response
- 20Hz-20KHz (±3dB)
- AC mains connector
- External PSU. Included 4 region power blades
- Power consumption
- 3W
- Video Input Connectors
- HDMI 2.0
HDMI® - HDMI Distance
- 10m / 33ft with Ecler VEO Cables
- Audio Input Connectors
- 1 x HDMI (ARC)
1 x S/PDIF Toslink
1 x S/PDIF Coaxial
1 x HDMI® (ARC)
1 x S/PDIF Toslink
1 x S/PDIF Coaxial - Audio Output Connectors
- 1 x 5pins Euroblock for Stereo Balanced Output (PCM 2.0)
1 x S/PDIF Toslink
1 x S/PDIF Coaxial - Audio Formats
- Dolby Digital, DTS 5.1, PCM
- Sample Rate
- up to 192KHZ
- Bit Depth
- 16 to 24-bit
- ARC/eARC
- ARC extractor
- Control Buttons
- 3-positions switch for input source selection
- Status Indicators
- 1 x red LED for power supply (POWER ON)
- Power supply
- External: Input 100-240 VAC @ 50/60Hz, Output 5VDC-1A
- DC mains connector
- DC Coaxial
- Chassis material
- Metal
- Release Date
- 16/06/2022
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
PHYSICAL
| Installation options |
Desktop - VEO-RACK19 |
|---|---|
| Operating temperature |
0 to 40°C (+32 to +104 °F) |
| Operating humidity |
5 - 90% RH (no condensation) |
| Included accessories |
Power supply, Euroblock 5-pin connectors, warranty card |
| Optional accessories |
VEO-RACK19 |
| Finished colour |
Black |
| Dimensions |
96.2 x 57.5 x 21 mm / 3.79 x 2.26 x 0.83 in. (WxHxD) |
| Weight |
0.14 kg / 0.309 lb |
| Shipping dimensions |
210 x 60 x 150 mm / 8.27 x 2.36 x 5.91 lb |
| Shipping weight |
0.4 kg / 0.88 lb |
| Format |
Unit |
| Chassis material |
Metal |
LOGISTICS
| Status |
New |
|---|---|
| Origin Production |
China |
| EAN code |
8435071315913
|
| Tariff code |
8517620000 |
| Shipping Location |
Spain |
| Width (cm) |
21 |
| Height (cm) |
6 |
| Depth (cm) |
15 |
| Vol. (dm3) |
1.89 |
| Gross Weight (kg) |
0.4 |
| Net Weight (kg) |
0.16 |
| Warranty (months) |
36 |
| Release Date |
16/06/2022 |
ELECTRICAL
| AC mains connector |
External PSU. Included 4 region power blades |
|---|---|
| Power consumption |
3W |
| Power supply |
External: Input 100-240 VAC @ 50/60Hz, Output 5VDC-1A |
| DC mains connector |
DC Coaxial |
DEVICE CONTROL
| Control Buttons |
3-positions switch for input source selection |
|---|---|
| Status Indicators |
1 x red LED for power supply (POWER ON) |
LINE OUTPUTS
| Frequency response |
20Hz-20KHz (±3dB) |
|---|
VIDEO PERFOMANCES
| Video Input Connectors |
HDMI 2.0 HDMI® |
|---|---|
| HDMI Distance |
10m / 33ft with Ecler VEO Cables |
AUDIO PERFORMANCES
| Audio Input Connectors |
1 x HDMI (ARC)
1 x S/PDIF Toslink
1 x S/PDIF Coaxial 1 x HDMI® (ARC) 1 x S/PDIF Toslink 1 x S/PDIF Coaxial |
|---|---|
| Audio Output Connectors |
1 x 5pins Euroblock for Stereo Balanced Output (PCM 2.0)
1 x S/PDIF Toslink
1 x S/PDIF Coaxial |
| Audio Formats |
Dolby Digital, DTS 5.1, PCM |
| Sample Rate |
up to 192KHZ |
| Bit Depth |
16 to 24-bit |
| ARC/eARC |
ARC extractor |
