MP4-10000
CLYMP410000
Check availability
Class D amplifier 2x4500W
The MP series are Class D amplifiers with a switching-mode power supply and PFC, designed for professional 2- and 4-channel installation and live applications.
Developed for use with a wide range of high-performance loudspeakers, the MP series, thanks to its high power output, allows for complete system configurations, offering versatility using only two amplifier models.
Thanks to its power factor correction system, it offers extremely low mains consumption and a wide operating range.
- Dimensions
- 483 x 482 x 45
- Weight
- 13,2 Kg / 29,10 lbs
- Frequency response
- 20 Hz - 20 KHz
- Crosstalk
- 70 dB
- AC mains requirement
- 100V -260V AC
- SNR
- 110 dBA
- Input impedance
- 20kΩ
- THD + Noise
- 0.5%
- Damping factor
- 5000
- AC protection
- Yes
- DC protection
- Yes
- Short-circuit protection
- Yes
Services and facilities implemented
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
PHYSICAL
| Dimensions |
483 x 482 x 45 |
|---|---|
| Weight |
13,2 Kg / 29,10 lbs |
ELECTRICAL
| AC mains requirement |
100V -260V AC |
|---|
ANALOGUE AUDIO OUTPUT PORTS
| Crosstalk |
70 dB |
|---|
SIGNAL
| SNR |
110 dBA |
|---|---|
| Damping factor |
5000 |
PROTECTIONS
| AC protection |
Yes |
|---|---|
| DC protection |
Yes |
| Short-circuit protection |
Yes |
LINE INPUTS
| Input impedance |
20kΩ |
|---|
LINE OUTPUTS
| Frequency response |
20 Hz - 20 KHz |
|---|---|
| THD + Noise |
0.5% |
OUTPUT POWER - All channels driven @ 1%THD
