MARS-8
CMARS8
Consultar disponibilidad
- Opciones de instalación
- Desktop, 19" rack
- Temperatura de funcionamiento
- Min: 0°C ; 32°F
Max: 40°C ; 104°F
- Humedad de funcionamiento
- 20 - 90% RH, no-condensing
- Temperatura de almacenamiento
- Min: -20°C ; -4°F
Max: 60°C ; 140°F
- Accesorios incluidos
- 1 x 24V/3.75A EU power Adapter, 16 x Euroblock 3-pin connectors, 1 x IR receiver, 1 x Remote Control
1 x 24V/3.75A EU power Adapter, 16 x Euroblock 3-pin connectors, 1 x IR receiver, 1 x Remote Control - Color acabado
- Black
- Dimensiones
- 432 × 44 × 300 mm / 17.01 × 1.73 × 11.81 in. (WxHxD)
432 × 44 × 300 mm / 17.01 × 1.73 × 11.81 in. (WxHxD) - Peso
- 3.9 Kg / 8.60 Ib
3.9 Kg / 8.60 Ib - Dimensiones de envío
- 590 × 80 × 500 mm / 23.23 × 3.15 × 19.69 in. (WxHxD)
590 × 80 × 500 mm / 23.23 × 3.15 × 19.69 in. (WxHxD) - Peso del envío
- 7.6 Kg / 16.76 Ib
7.6 Kg / 16.76 Ib - Frequency response
- 20Hz-20KHz (±3dB)
- AC mains connector
- External PSU. Included 4 region power blades (UK,US,AU,EU)
- Consumo de energía
- 70W
70W - Video Input Connectors
- 8 x HDMI® Type A Female, 2.0b, 18 Gbps
- Video Output Connectors
- 8 x HDMI® Type A Female, 2.0b, 18 Gbps
8 x HDMI® Type A Female, 2.0b, 18 Gbps - Video Input Resolutions
- 480i, 480p, 720i, 720p, 1080i, 1080p, 4K up to 60Hz
- Video Output Resolutions
- 480i, 480p, 720i, 720p, 1080i, 1080p, 4K up to 60Hz
- Chroma Subsampling
- 4:4:4, 4:2:2, 4:2:0
- Colour Depth
- 8-bit (4K 60Hz 4:4:4) , 10-bit / 12-bit (4K 30Hz 4:2:2 – 4:2:0)
8-bit (4K 60Hz 4:4:4) , 10-bit / 12-bit (4K 30Hz 4:2:2 – 4:2:0) - Colour Space
- RGB, YCbCr (4:4:4 - 4:2:2), YUV (4:2:0)
- HDCP
- 2.2
- HDR
- HDR, HDR10, HDR10+, Dolby Vision, HLG
- Audio Input Connectors
- No
- Audio Output Connectors
- 16 x 3-pin Euroblock connector (8 x Stereo Balanced Out),
8 x Toslink Out connector
16 x 3-pin Euroblock connector (8 x Stereo Balanced Out),
8 x Toslink Out connector
- Audio Formats
- LPCM 2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio
- Sample Rate
- 24KHz, 96KHz
- Bit Depth
- Up to 24-bit
- ARC/eARC
- No
- Control Buttons
- Stby, Lock, Settings, Input/Output Selection
- EDID Management
- Control Screen, Web GUI, Remote control commands
- Status Indicators
- Stby LED, Lock LED, LCD Display
- Pass-through Connectors
- 1 x RS-232, 8 x Jack 3,5mm, 1 x HDMI
1 x RS-232, 8 x Jack 3,5mm, 1 x HDMI - Alimentación
- External Power supply External: Input 100-240 VAC - 50/60Hz, Output: 24VDC-3.75A
- DC mains connector
- DC Coaxial
- Chassis material
- Metal
- Pass-through Protocols
- IR, CEC
- Control Connectors
- 1 x RJ45, 1 x RS-232, 1 x 3-pin Euroblock, 1 x Jack 3,5mm
1 x RJ45, 1 x RS-232, 1 x 3-pin Euroblock, 1 x Jack 3,5mm - Audio De-Embedding
- Yes
- Audio Embedding
- No
- Control Protocols
- Web, TCP, Telnet, RS-232, IR, IR remote Control
- Video Composing Capabilities
- Videowall: up to 8 screens with splicing feature
Multiviewing: up to 8 windows
- Scaling Features
- Yes
- Seamless Switching
- Yes
Servicios e instalaciones implementadas
¿Necesitas ayuda?
Contacta con el comercial más cercano
Encuentra a tu comercial
Si ya conoces a tu comercial asignado inicia sesión para contactar directamente
O déjanos aquí tus dudas y nuestros expertos te ayudarán
FÍSICO
| Opciones de instalación |
Desktop, 19" rack |
|---|---|
| Temperatura de funcionamiento |
Min: 0°C ; 32°F
Max: 40°C ; 104°F
|
| Humedad de funcionamiento |
20 - 90% RH, no-condensing |
| Temperatura de almacenamiento |
Min: -20°C ; -4°F
Max: 60°C ; 140°F
|
| Accesorios incluidos |
1 x 24V/3.75A EU power Adapter, 16 x Euroblock 3-pin connectors, 1 x IR receiver, 1 x Remote Control 1 x 24V/3.75A EU power Adapter, 16 x Euroblock 3-pin connectors, 1 x IR receiver, 1 x Remote Control |
| Color acabado |
Black |
| Dimensiones |
432 × 44 × 300 mm / 17.01 × 1.73 × 11.81 in. (WxHxD) 432 × 44 × 300 mm / 17.01 × 1.73 × 11.81 in. (WxHxD) |
| Peso |
3.9 Kg / 8.60 Ib 3.9 Kg / 8.60 Ib |
| Dimensiones de envío |
590 × 80 × 500 mm / 23.23 × 3.15 × 19.69 in. (WxHxD) 590 × 80 × 500 mm / 23.23 × 3.15 × 19.69 in. (WxHxD) |
| Peso del envío |
7.6 Kg / 16.76 Ib 7.6 Kg / 16.76 Ib |
| Chassis material |
Metal |
ELECTRICAL
| AC mains connector |
External PSU. Included 4 region power blades (UK,US,AU,EU) |
|---|---|
| Consumo de energía |
70W 70W |
| Alimentación |
External Power supply External: Input 100-240 VAC - 50/60Hz, Output: 24VDC-3.75A |
| DC mains connector |
DC Coaxial |
DEVICE CONTROL
| Control Buttons |
Stby, Lock, Settings, Input/Output Selection |
|---|---|
| EDID Management |
Control Screen, Web GUI, Remote control commands |
| Status Indicators |
Stby LED, Lock LED, LCD Display |
| Control Connectors |
1 x RJ45, 1 x RS-232, 1 x 3-pin Euroblock, 1 x Jack 3,5mm 1 x RJ45, 1 x RS-232, 1 x 3-pin Euroblock, 1 x Jack 3,5mm |
| Control Protocols |
Web, TCP, Telnet, RS-232, IR, IR remote Control |
LINE OUTPUTS
| Frequency response |
20Hz-20KHz (±3dB) |
|---|
VIDEO PERFOMANCES
| Video Input Connectors |
8 x HDMI® Type A Female, 2.0b, 18 Gbps |
|---|---|
| Video Output Connectors |
8 x HDMI® Type A Female, 2.0b, 18 Gbps 8 x HDMI® Type A Female, 2.0b, 18 Gbps |
| Video Input Resolutions |
480i, 480p, 720i, 720p, 1080i, 1080p, 4K up to 60Hz |
| Video Output Resolutions |
480i, 480p, 720i, 720p, 1080i, 1080p, 4K up to 60Hz |
| Chroma Subsampling |
4:4:4, 4:2:2, 4:2:0 |
| Colour Depth |
8-bit (4K 60Hz 4:4:4) , 10-bit / 12-bit (4K 30Hz 4:2:2 – 4:2:0) 8-bit (4K 60Hz 4:4:4) , 10-bit / 12-bit (4K 30Hz 4:2:2 – 4:2:0) |
| Colour Space |
RGB, YCbCr (4:4:4 - 4:2:2), YUV (4:2:0) |
| HDCP |
2.2 |
| HDR |
HDR, HDR10, HDR10+, Dolby Vision, HLG |
| Video Composing Capabilities |
Videowall: up to 8 screens with splicing feature
Multiviewing: up to 8 windows
|
| Scaling Features |
Yes |
| Seamless Switching |
Yes |
AUDIO PERFORMANCES
| Audio Input Connectors |
No |
|---|---|
| Audio Output Connectors |
16 x 3-pin Euroblock connector (8 x Stereo Balanced Out),
8 x Toslink Out connector
16 x 3-pin Euroblock connector (8 x Stereo Balanced Out), 8 x Toslink Out connector |
| Audio Formats |
LPCM 2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio |
| Sample Rate |
24KHz, 96KHz |
| Bit Depth |
Up to 24-bit |
| ARC/eARC |
No |
| Audio De-Embedding |
Yes |
| Audio Embedding |
No |
PASS-THROUGH CONTROL
| Pass-through Connectors |
1 x RS-232, 8 x Jack 3,5mm, 1 x HDMI 1 x RS-232, 8 x Jack 3,5mm, 1 x HDMI |
|---|---|
| Pass-through Protocols |
IR, CEC |
