CVOIT3990
Check availability
4-channel stage for installation.
See more Features

The four-channel Bias Q3 DSP touring amplifier provides reliable premium-grade power with intuitive front panel control. The Q3 offers ample power, allowing for high SPL even with 8 or 16 Ω loads, and is capable of delivering 4 x 2000 W output on 4 Ω loads, increasing to 2300 W when driven asymmetrically. This amplifier has been designed with versatility and ease of use in mind, and is suitable for high-power, full-range systems in any configuration. As with all other Bias amplifiers, it offers total integration with the Armonia Pro Audio Suite™ enabling extended control on smart phones and tablets.
Dimensions
483 x 381 x 88,9 mm (19 x 15 x 3,5 in)
Weight
11,5 Kg (25,4 Ibs)
Status
New
EAN code
IT3752
IT3990
IT3990
Tariff code
8518400000
Shipping Location
Spain
Frequency response
20 Hz - 20 kHz +/- 1.0 dB @ 8 Ω load
Input sensitivity
32 dB
Number of output channels
4 x Speakon NL4
Number of input channels
4 Dante/AES67 TX (from local input or DSP)
Input connection type
4 (2x XLR)/ 4 x XLR male (LINK)
4x XLR female/ 4 x XLR male (LINK)
Max input level
24 dBu
THD + Noise
0.1% (typical 0.05%) (from 0.1 W to Half Power)
<0.1% (typical < 0.05%) (from 0.1 W to Half Power)
AD converters
24 Bit Tandem™ @ 48 kHz
125 dB-A Dynamic Range - 0.005 % THD+N
DA converters
24 Bit Tandem™ @ 48 kHz
117 dB Dynamic Range - 0.003 % THD+N
Sample rate converter
24 Bit @ 96 kHz
140 dB Dynamic Range - 0.0001 % THD+N
Internal precision
32 bit floating point
Latency
2.5 ms fixed latency architecture
Memory/Presets
50 amplifier snapshots, virtually unlimited speaker presets
Delay
2 s (input) + 100 ms (output) for time alignment
Equalizer
Raised-cosine, custom FIR, parametric IIR:
peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass
Crossover
linear phase (FIR), Butterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
Limiters
TruePower™, RMS voltage, RMS current, Peak limiter
Damping control
Active DampingControl™ and LiveImpedance™ measurement
Power Consumption (IDLE)
33.7 W @ 100 V/ 33.5 W @ 240 V
Power Consumption (STBY)
15.8 W @ 100 V/ 17.2 W @ 240 V
Ethernet
Two Gigabit Ethernet ports, integrated switch, Ethercon connectors
Power Consumption (STBY/SLEEP)
15.8 W @ 100 V/ 17.2 W @ 240 V

Customers who bought this product also bought:

Customers who bought this product also bought:

Services and facilities implemented

see solutions

Ecler at Áltima

Multi-zone sound system installation designed to improve speech intelligibility and ensure consistent coverage across indoor and outdoor ceremony spaces.

Centers of worship

Void at Dido The Real Show

Immersive sound that complements gastronomy, live entertainment and music in every corner of the venue.

Leisure

Opus | Auracast™ at Eurovisión 2026

Auracast™ enabled assisted listening at Eurovision 2026 in an extremely complex RF environment, ensuring audio accessibility without the need for wired infrastructure.

Leisure

LYNX EN TERRAZA BAGHEERA

Terraza Bagheera in Toledo debuts its new sound system, delivering balanced coverage across all areas, from the dance floor to the most remote corners.

Leisure

New Ecler price list available

News

Void Acoustics Air 12 now available

News

Ecler en Zegna

Retail

Void at Dido The Real Show

Immersive sound that enhances gastronomy, live performance, and music in every corner.

Void Acoustics

Ecler en el campo del CD Tondela

Sports & Wellness

Void Acoustics en primera edición Soundit Festiv

Void Acoustics

¿Necesitas ayuda?

Contacta con el comercial más cercano

Encuentra a tu comercial

Si ya conoces a tu comercial asignado inicia sesión para contactar directamente

O déjanos aquí tus dudas y nuestros expertos te ayudarán

SYSTEM
Number of input channels 4 Dante/AES67 TX (from local input or DSP)
PHYSICAL
Dimensions 483 x 381 x 88,9 mm (19 x 15 x 3,5 in)
Weight 11,5 Kg (25,4 Ibs)
LOGISTICS
Status New
EAN code IT3752 IT3990
IT3990
Tariff code 8518400000
Shipping Location Spain
AUDIO CONVERTERS
Latency 2.5 ms fixed latency architecture
CONNECTIVITY
Ethernet Two Gigabit Ethernet ports, integrated switch, Ethercon connectors
CHANNELS
Number of output channels 4 x Speakon NL4
POWER CONSUMPTION
Power Consumption (IDLE) 33.7 W @ 100 V/ 33.5 W @ 240 V
Power Consumption (STBY) 15.8 W @ 100 V/ 17.2 W @ 240 V
Power Consumption (STBY/SLEEP) 15.8 W @ 100 V/ 17.2 W @ 240 V
DSP
AD converters 24 Bit Tandem™ @ 48 kHz 125 dB-A Dynamic Range - 0.005 % THD+N
DA converters 24 Bit Tandem™ @ 48 kHz 117 dB Dynamic Range - 0.003 % THD+N
Sample rate converter 24 Bit @ 96 kHz 140 dB Dynamic Range - 0.0001 % THD+N
Internal precision 32 bit floating point
Memory/Presets 50 amplifier snapshots, virtually unlimited speaker presets
Delay 2 s (input) + 100 ms (output) for time alignment
Equalizer Raised-cosine, custom FIR, parametric IIR: peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass
Crossover linear phase (FIR), Butterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
Limiters TruePower™, RMS voltage, RMS current, Peak limiter
Damping control Active DampingControl™ and LiveImpedance™ measurement
ANALOGUE AUDIO INPUTS
Input sensitivity 32 dB
LINE INPUTS
Input connection type 4x XLR female/ 4 x XLR male (LINK)
4 (2x XLR)/ 4 x XLR male (LINK)
Max input level 24 dBu
LINE OUTPUTS
Frequency response 20 Hz - 20 kHz +/- 1.0 dB @ 8 Ω load
THD + Noise <0.1% (typical < 0.05%) (from 0.1 W to Half Power)
0.1% (typical 0.05%) (from 0.1 W to Half Power)
