eGPA8-150

Reference CEGPA8150C

Check availability

8x150 WRMS | class D | stereo | amplifier

See more Features

Description
Product Details

eGPA8-150 is an 8x150 W RMS @ 4 ohm, high efficiency multichannel amplifier (class D). Auto stand-by function and fanless design, 100% silent. Thermal and overload protections. Anti-clip system.

Installation options: 19" rack format (1RU)
Operating temperature: Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity: 85% HR
<85% HR
Storage temperature: Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity: 90% HR
<90% HR
Dimensions: 440 x 44 x 361 mm / 17.32 x 1.73 x 14.21 in. (WxHxD)
Weight: 6.5 kg / 14.43 lb
Shipping dimensions: 510 x 70 x 590 mm / 20.1 x 2.76 x 23.23 in. (WxHxD)
Shipping weight: 7.9 kg / 17.42 lb
Status: New
Origin Production: Spain
EAN code: 8435071308236
Tariff code: 8518400000
Shipping Location: Spain
Width (cm): 51.00
Height (cm): 7.00
Depth (cm): 59.00
Vol. (dm3): 21.06
Gross Weight (kg): 7.90
Net Weight (kg): 6.90
Format: Unit
Warranty (months): 36
Frequency response: 20Hz - 25kHz (-1dB, -3dB)
Input sensitivity: 0dB
CMRR: 55dB
>55dB
Crosstalk: 55dB @ 1kHz

>55dB @ 1kHz
AC mains requirement: 100-240 V @ 50-60Hz
AC mains connector: AC socket connector (IEC)
Power supply: Universal, regulated switch mode with PFC (Power Factor Correction)
SNR: 85dB 20Hz - 20kHz @ 1W/4Ω
>85dB 20Hz - 20kHz @ 1W/4Ω
Output connection type: Euroblock
Number of output channels: 8
Number of input channels: 8
Input connection type: Euroblock
Input impedance: 20kΩ (10kΩ unbalanced)
>20kΩ (10kΩ unbalanced)
THD + Noise: 0.05% @ 1kHz Full Power
<0.05% @ 1kHz Full Power
Damping factor: 150 1kHz @ 8Ω
>150 1kHz @ 8Ω
Cooling: Convection (fanless)
Power Consumption (IDLE): 58 W
Power Consumption (STBY): 36 W
Output configuration: 8x150 W RMS @ 4 Ω
Input configuration: Analogue audio inputs
Power Consumption (1/3 POWER, @ 4Ω): pink noise, 536 W
Power Consumption (1/8 POWER, @ 4Ω): pink noise, 226 W / 260 VA
Energy save: Auto standby function
Efficiency: 80% @ max power
AC protection: No
DC protection: No
VHF protection: No
Short-circuit protection: Yes
Clip limiter: Yes
Long term limiter: No
Thermal protection: Yes
Attenuators: Front panel knobs per channel
Output settings: Operating mode selector: STEREO, MONO - BRIDGE (Lo-Z)
Auto stand-by function: Front panel switch
Auto stand-by time: 90 seconds
Signal Present: SP LED (Green) per channel
Cliping: CLIP LED (Red) per channel
Standby: STBY LED (Orange)
Filters: 15Hz 3rd order Butterworth Hihg-Pass filter
Auto standby time: 90 seconds
Amplification technology: Class D
Power ON/OFF: Front panel switch & indicator
Thermal: TH LED (Red)
Protect: PROT LED (Red)
Energy saving: Auto standby function
Power Consumption (STBY/SLEEP): 36 W
Auto standby function: Front panel switch
Power Consumption (1/3 POWER, @ 4Ω all channels driven): pink noise, 536 W
Power Consumption (1/8 POWER, @ 4Ω all channels driven): pink noise, 226 W / 260 VA

Services and facilities implemented

Ecler at Áltima

Multi-zone sound system installation designed to improve speech intelligibility and ensure consistent coverage across indoor and outdoor ceremony spaces.

Void at Dido The Real Show

Immersive sound that complements gastronomy, live entertainment and music in every corner of the venue.

Opus | Auracast™ at Eurovisión 2026

Auracast™ enabled assisted listening at Eurovision 2026 in an extremely complex RF environment, ensuring audio accessibility without the need for wired infrastructure.

LYNX EN TERRAZA BAGHEERA

Terraza Bagheera in Toledo debuts its new sound system, delivering balanced coverage across all areas, from the dance floor to the most remote corners.

New Ecler price list available

Void Acoustics Air 12 now available

Ecler en Zegna

Void at Dido The Real Show

Immersive sound that enhances gastronomy, live performance, and music in every corner.

Ecler en el campo del CD Tondela

Void Acoustics en primera edición Soundit Festiv

¿Necesitas ayuda?

Contacta con el comercial más cercano

Encuentra a tu comercial

Si ya conoces a tu comercial asignado inicia sesión para contactar directamente

O déjanos aquí tus dudas y nuestros expertos te ayudarán

Subject

Email address

Attachment

Message

I agree to the terms and conditions and the privacy policy

SYSTEM

Number of input channels	8

PHYSICAL

Installation options	19" rack format (1RU)
Operating temperature	Min: -10°C ; 14°F Max: 40°C ; 104°F
Operating humidity	<85% HR 85% HR
Storage temperature	Min: -10°C ; 14°F Max: 40°C ; 104°F
Storage humidity	<90% HR 90% HR
Dimensions	440 x 44 x 361 mm / 17.32 x 1.73 x 14.21 in. (WxHxD)
Weight	6.5 kg / 14.43 lb
Shipping dimensions	510 x 70 x 590 mm / 20.1 x 2.76 x 23.23 in. (WxHxD)
Shipping weight	7.9 kg / 17.42 lb
Format	Unit

LOGISTICS

Status	New
Origin Production	Spain
EAN code	8435071308236
Tariff code	8518400000
Shipping Location	Spain
Width (cm)	51.00
Height (cm)	7.00
Depth (cm)	59.00
Vol. (dm3)	21.06
Gross Weight (kg)	7.90
Net Weight (kg)	6.90
Warranty (months)	36

ELECTRICAL

AC mains requirement	100-240 V @ 50-60Hz
AC mains connector	AC socket connector (IEC)
Power supply	Universal, regulated switch mode with PFC (Power Factor Correction)

ANALOGUE AUDIO OUTPUT PORTS

Crosstalk	>55dB @ 1kHz 55dB @ 1kHz

CHANNELS

Number of output channels	8
Output configuration	8x150 W RMS @ 4 Ω
Input configuration	Analogue audio inputs

SIGNAL

SNR	>85dB 20Hz - 20kHz @ 1W/4Ω 85dB 20Hz - 20kHz @ 1W/4Ω
Damping factor	>150 1kHz @ 8Ω 150 1kHz @ 8Ω

POWER CONSUMPTION

Power Consumption (IDLE)	58 W
Power Consumption (STBY)	36 W
Power Consumption (1/3 POWER, @ 4Ω)	pink noise, 536 W
Power Consumption (1/8 POWER, @ 4Ω)	pink noise, 226 W / 260 VA
Power Consumption (STBY/SLEEP)	36 W
Power Consumption (1/3 POWER, @ 4Ω all channels driven)	pink noise, 536 W
Power Consumption (1/8 POWER, @ 4Ω all channels driven)	pink noise, 226 W / 260 VA

TECHNOLOGIES

Cooling	Convection (fanless)
Energy save	Auto standby function
Efficiency	80% @ max power
Amplification technology	Class D
Energy saving	Auto standby function

PROTECTIONS

AC protection	No
DC protection	No
VHF protection	No
Short-circuit protection	Yes
Clip limiter	Yes
Long term limiter	No
Thermal protection	Yes

SETTINGS

Output settings	Operating mode selector: STEREO, MONO - BRIDGE (Lo-Z)
Auto stand-by function	Front panel switch
Auto stand-by time	90 seconds
Auto standby function	Front panel switch

MONITORING

Signal Present	SP LED (Green) per channel
Cliping	CLIP LED (Red) per channel
Standby	STBY LED (Orange)
Thermal	TH LED (Red)
Protect	PROT LED (Red)

ANALOGUE AUDIO INPUTS

Input sensitivity	0dB

MONITORING AND CONTROL

Auto standby time	90 seconds

MIC INPUTS

Filters	15Hz 3rd order Butterworth Hihg-Pass filter

LINE INPUTS

CMRR	>55dB 55dB
Input connection type	Euroblock
Input impedance	>20kΩ (10kΩ unbalanced) 20kΩ (10kΩ unbalanced)

LINE OUTPUTS

Frequency response	20Hz - 25kHz (-1dB, -3dB)
Output connection type	Euroblock
THD + Noise	<0.05% @ 1kHz Full Power 0.05% @ 1kHz Full Power

LOCAL CONTROL

Attenuators	Front panel knobs per channel
Power ON/OFF	Front panel switch & indicator

OUTPUT POWER - All channels driven @ 1%THD
