eGPA2-150
eGPA2-150
eGPA2-150
eGPA2-150

eGPA2-150

CEGPA2150C
Check availability
2x150 WRMS | class D | stereo | amplifier
See more Features

eGPA2-150 is a stereo, 2x150 W RMS @ 4 Ω, high efficiency amplifier (class D). Auto stand-by function and fanless design, 100% silent. Thermal and overload protections. Anti-clip system.
Installation options
19" rack format (1RU)
Operating temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity
85% HR
<85% HR
Storage temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity
90% HR
<90% HR
Dimensions
440 x 44 x 161 mm / 17.32 x 1.73 x 6.34 in. (WxHxD)
Weight
2.65 kg / 5.84 lb
Shipping dimensions
320 x 70 x 590 mm / 12.6 x 2.76 x 23.23 in. (WxHxD)
Shipping weight
3.7 kg / 8.16 lb
Status
New
Origin Production
Spain
EAN code
8435071308168
Tariff code
8518400000
Shipping Location
Spain
Width (cm)
32.00
Height (cm)
7.00
Depth (cm)
59.00
Vol. (dm3)
13.22
Gross Weight (kg)
3.70
Net Weight (kg)
2.70
Format
Unit
Warranty (months)
36
Frequency response
20Hz - 25kHz (-1dB, -3dB)
Input sensitivity
0dB
CMRR
55dB

>55dB
Crosstalk
55dB @ 1kHz
>55dB @ 1kHz
AC mains requirement
100-240VAC @ 50-60Hz
AC mains connector
AC socket connector (IEC)
Power supply
Universal, regulated switch mode with PFC (Power Factor Correction)
SNR
85dB 20Hz - 20kHz @ 1W/4Ω

>85dB 20Hz - 20kHz @ 1W/4Ω
Output connection type
Euroblock
Number of output channels
2
Number of input channels
2
Input connection type
Euroblock
Input impedance
20kΩ (10kΩ unbalanced)

>20kΩ (10kΩ unbalanced)
THD + Noise
0.05% @ 1kHz Full Power
<0.05% @ 1kHz Full Power
Damping factor
150 1kHz @ 8Ω
>150 1kHz @ 8Ω
Cooling
Convection (fanless)
Power Consumption (IDLE)
19 W
Power Consumption (STBY)
13 W
Output configuration
2x150 W RMS @ 4 Ω
Input configuration
Analogue audio inputs
Power Consumption (1/3 POWER, @ 4Ω)
pink noise, 139 W
Power Consumption (1/8 POWER, @ 4Ω)
pink noise, 63 W / 74 VA
Energy save
Auto standby function
Efficiency
77% @ max power
AC protection
No
DC protection
No
VHF protection
No
Short-circuit protection
Yes
Clip limiter
Yes
Long term limiter
No
Thermal protection
Yes
Attenuators
Front panel knobs per channel
Output settings
Operating mode selector: STEREO, MONO - BRIDGE (Lo-Z)
Auto stand-by function
Front panel switch
Auto stand-by time
90 seconds
Signal Present
SP LED (Green) per channel
Cliping
CLIP LED (Red) per channel
Standby
STBY LED (Orange)
Filters
15Hz 3rd order Butterworth High-Pass filter
Auto standby time
90 seconds
Amplification technology
Class D
Power ON/OFF
Front panel switch & indicator
Thermal
TH LED (Red)
Protect
PROT LED (Red)
Energy saving
Auto standby function
Power Consumption (STBY/SLEEP)
13 W
Auto standby function
Front panel switch
Power Consumption (1/3 POWER, @ 4Ω all channels driven)
pink noise, 139 W
Power Consumption (1/8 POWER, @ 4Ω all channels driven)
pink noise, 63 W / 74 VA
